Australia: 1300 232 476 New Zealand: 09 927 7140 www.AFLglobal.com Fibre Passive Devices 1 © 2002-2023, AFL, all rights reserved. 0347, Revision 5, 30.06.23 Specifications are subject to change without notice. AFL's optical circulators are designed to increase capacity on existing fibre infrastructure. Available in two configurations, a single wavelength (1310 nm or 1550 nm) and dual wavelength OCW model (1310 nm and 1550 nm), they halve the numbers of link fibres required per wavelength. Designed to be Plug and Play, they can be quickly and easily deployed with minimal service interruption to existing circuits. Features • Plug and Play design • Optimise fibre utilisation • Scaleable modular design or 1RU variations • Customisation also available Optical Circulators Applications • LAN/SAN Circulator Specifications Wavelength (nm) 1310 or 1500 +/- 30 nm Insertion loss* (dB) 0.6 Isolation - Port 2-1, Port 3-2 (dB) ≥ 50 Return loss (dB) ≥ 50 Polarisation dependent loss (dB) < 1.0 PMD (ps) < 1.0 Power handling (mW) 300 Fibre type G652.D * Insertion loss excludes connectors OCW Specifications Wavelength (nm) 1310 or 1550 +/- 15 nm Insertion loss* (dB) 1.3 Tx / Rx Port Isolation (dB) ≥ 50 Return loss (dB) ≥ 50 Polarisation dependent loss (dB) < 1.0 PMD (ps) < 1.0 Power handling (mW) 300 * Insertion loss excludes connectors 1RU Optical Circulator 1RU OCW Australia: 1300 232 476 New Zealand: 09 927 7140 www.AFLglobal.com Fibre Passive Devices 2 © 2002-2023, AFL, all rights reserved. 0347, Revision 5, 30.06.23 Specifications are subject to change without notice. Circulator Module DESCRIPTION PART NUMBER 6 x Circulator, 1310 nm, SCA/SC, 1RU Rackmount FPD-OC113SCASC6-X1 6 x Circulator, 1550 nm, SCA/SC, 1RU Rackmount FPD-OC115SCASC6-X1 8 x Circulator, 1310 nm, SCA/LC, 1RU Rackmount FPD-OC113SCALC8-X1 8 x Circulator, 1550 nm, SCA/LC, 1RU Rackmount FPD-OC115SCALC8-X1 Circulator HD Module DESCRIPTION PART NUMBER 4 x Circulator, 1310 nm, SCA/SC, HD Module FPD-OC113SCASC4-H1 6 x Circulator, 1310 nm, SCA/LC, HD Module FPD-OC113SCALC6-H1 4 x Circulator, 1550 nm, SCA/SC, HD Module FPD-OC115SCASC4-H1 6 x Circulator, 1550 nm, SCA/LC, HD Module FPD-OC115SCALC6-H1 3 x Circulator, 1310 nm / 3 x Circulator, 1550nm, SCA/LC, HD Module FPD-OC11315SCALC3-H1 Circulator XHD Module DESCRIPTION PART NUMBER 8 x Circulator, 1310 nm, LCA/LC, XHD Module FPD-OC113LCALC8-XHD1 8 x Circulator, 1550 nm, LCA/LC, XHD Module FPD-OC115LCALC8-XHD1 Circulator IFDF Module DESCRIPTION PART NUMBER 12 x Circulator, 1310 nm, SCA/LC, IFDF Module FPD-OC113SCALC12-F1 12 x Circulator, 1550 nm, SCA/LC, IFDF Module FPD-OC115SCALC12-F1 8 x Circulator, 1310 nm, LCA/LC, XHD Module FPD-OC113LCALC8-XHD1 8 x Circulator, 1550 nm, LCA/LC, XHD Module FPD-OC115LCALC8-XHD1 OCW HD Module DESCRIPTION PART NUMBER 2 x OCW, 1310/1550 nm, SCA/SC, HD Module FPD-OCW1SCASC2-H1 4 x OCW, 1310/1550 nm, SCA/LC, HD Module FPD-OCW1SCALC4-H1 4 x OCW, 1310/1550 nm, SCA/LC, IFDF FPD-OCW1SCALC4-F1 OCW Rackmount DESCRIPTION PART NUMBER 4 x OCW, 1310/1550 nm, SCA/SC, 1RU Rackmount FPD-OCW1SCASC4-X1 6 x OCW, 1310/1550 nm, SCA/LC, 1RU Rackmount FPD-OCW1SCALC6-X1 Ordering Information Environmental Specifications Operating temperature (ºC) -0 - +70 Storage temperature (ºC) -40 - +85 CONNECTOR PERFORMANCE LC, SC, ST and FC connectors* SINGLEMODE UPC @ 1310 and 1550 nm APC @ 1310 and 1550 nm Average Max / Min Average Max / Min Insertion loss (dB) 0.10 0.25 Max 0.15 0.25 Max Return loss (dB) 58 55 Min 70 65 Min * Please contact AFL for performance on other connectors
