18 © 2008, AFL, all rights reserved PP-4-00036, Revision 5 , 4 14 16 Specifications are subject to change without notice Specifications PARAMETER VALUE Fiber Cladding 80 - 125 μm* Fiber Coating 160 - 400 μm* Cleave Angle Typical < 0 3º Cycle Time Typical < 14 seconds Cladding diameter 80 and 125 μm # of Cleaves/Blade > 30,000 Fiber Waste Typical < 20 mm Power Supply External 12V DC Compressed Air External Compressor**, 6 bar 4 mm instant push-in fitting PC connection RS-232 Dimensions 175 mm (W) x 138 mm (D) x 104 mm (H) Weight 1 4 kg * Fiber specific handling kits required ** Not included in delivery a + / - 10 μm AutoCleaver S1 -80 μm / S1-125 μm Ordering Information DESCRIPTION AFL NO. AutoCleaver S1-80 μm with Power Supply and Cord (Includes: V-groove & Height Adjuster, Adaptor Plate, PC software, manual and tools) 50100029 AutoCleaver S1-125 μm with Power Supply and Cord (Includes: V-groove & Height Adjuster, Adaptor Plate, PC software, manual and tools) 50100028 Accessories DESCRIPTION AFL NO. Adaptor Plate FJK, AC STD 50100010 Adaptor Plate NYF/ECA, AC STD 50000030 V-groove, STD, Cla 80 μm 50100089 V-groove, STD, Cla 125-199 μm 50100085 Height Adj STD, Cla 80 μm 50100052 Height Adj STD Cla 125-159 μm 50100046 Diamond blade 50100091 Cleaver Blade Replacement Tool 50100032 Power Supply, 100-240V, 1 25 A 50100075 Adapter for Power Supply, US 50100009 Features • Fully automatic • Low cleave angles of < 0 3º • Very flat end faces • Operator independent • Designed for production environment • Waste fiber deposition • Long diamond life • Available for 80 or 125 μm fibers • PC controllable When a specific and accurate bare fiber length is required, the AutoCleaver S1 provides the perfect cleave every time Sensing the edge of the coating and adjusting the bare fiber length according to the customers’ specifications, the AutoCleaver S1 cleaves 80 μm and 125 μm fibers automatically Cleave angles are typically under 0 3° with excellent end face quality A built-in microprocessor controls all the vital parameters and settings such as fiber positioning, clamping, fiber tension and the exact position and speed of the diamond blade The cleaver can be connected to an external PC, enabling access to all programmable parameters and settings The AutoCleaver S1 is available in a small bench top design, workbench-mountable or ready to be integrated into different sub-systems At the time of order, the desired cleave length must be specified The minimum cleave length possible is 3 mm and the maximum is 6 5 mm The bare fiber length can be fine-tuned by software between 0 and 500 μm
