Fiber Optic Inspection Adapter Tips Reference Guide Connector Adapters Reference Guide OTDRs | Certification Testers | Fiberscopes | Loss Test Sets 2 ROGUE OTDR and OLTS/CERT Modules, M Series OTDRs Connector Adapters for the OTDR/OLS, OPM, and VFL Test Ports IMAGE TYPE PORT AFL NO. FC OTDR/OLS 2900-50-0002MR SC OTDR/OLS 2900-50-0003MR ST OTDR/OLS 2900-50-0004MR LC OTDR/OLS 2900-50-0006MR FC OPM 2900-52-0001MR SC OPM 2900-52-0002MR IMAGE TYPE PORT AFL NO. ST OPM 2900-52-0003MR LC OPM 2900-52-0004MR 2.5 mm Universal OPM 2900-52-0005MR 1.25 mm Universal OPM 2900-52-0006MR 2.5 mm Universal VFL 2900-50-0007MR 1.25 mm Universal VFL 2900-50-0010MR 3 FlexScan ® FS200, FlexTester FLX380 and OFL280 Series Connector Adapters for the OTDR/OLS, OPM, and VFL Test Ports IMAGE TYPE PORT AFL NO. FC OTDR/OLS 2900-50-0002MR SC OTDR/OLS 2900-50-0003MR ST OTDR/OLS 2900-50-0004MR LC OTDR/OLS 2900-50-0006MR SC/APC OTDR/OLS 2900-50-0011MR FC OPM 2900-52-0001MR SC OPM 2900-52-0002MR IMAGE TYPE PORT AFL NO. ST OPM 2900-52-0003MR LC OPM 2900-52-0004MR 2.5 mm Universal OPM 2900-52-0005MR 1.25 mm Universal OPM 2900-52-0006MR 2.5 mm Universal VFL 2900-53-0001MR 1.25 mm Universal VFL 2900-53-0002MR 4 M710 Series Compact OTDRs Connector Adapters for the OTDR, OPM, and VFL Test Ports IMAGE TYPE PORT AFL NO. FC OTDR 2900-50-0002MR SC OTDR 2900-50-0003MR ST OTDR 2900-50-0004MR LC OTDR 2900-50-0006MR FC OPM 8800-00-0200 SC OPM 8800-00-0209 IMAGE TYPE PORT AFL NO. ST OPM 8800-00-0202 LC OPM 8800-00-0225 2.5 mm Universal OPM 8800-00-0214 1.25 mm Universal OPM 8800-00-0224 2.5 mm Universal VFL 2900-53-0001MR 1.25 mm Universal VFL 2900-53-0002MR 5 OLS Series Optical Light Sources Connector Adapters for the OLS Ports OPM Series Power Meters and OFS300 & VS300 Inspection Scopes Connector Adapters for OPM Power Meters and OFS300 & VS300 Inspection Scopes IMAGE TYPE AFL NO. FC 2900-50-0002MR SC 2900-50-0003MR IMAGE TYPE AFL NO. ST 2900-50-0004MR LC 2900-50-0006MR IMAGE TYPE AFL NO. FC 8800-00-0200 SC 8800-00-0209 ST ® 8800-00-0202 LC Simplex only 8800-00-0225 IMAGE TYPE AFL NO. LC duplex only 8800-00-0273PR 2.5 mm Universal Accepts FC, SC, ST ferrules 8800-00-0214 1.25 mm Universal Accepts LC, MU ferrules 8800-00-0224 2.5 mm, open Universal (for OptiTap connectors) 8800-00-0219 6 OPM Series Power Meters and OFS300-200 & VS300 Inspection Scopes Connector Adapters for OPM Power Meters and OFS300-200 & VS300 Inspection Scopes IMAGE TYPE AFL NO. E-2000 8800-00-0221 MU Simplex 8800-00-0226 MT-RJ (A side only) 8800-00-0230 MT-RJ (A side or B side) 8800-00-0231 SMA 8800-00-0203 D4 8800-00-0201 IMAGE TYPE AFL NO. Biconic 8800-00-0204 DIN 47256 8800-00-0211 PFO/VFO (Radiall) 8800-00-0212 Adapters for Plastic Optical Fiber (POF) IMAGE TYPE AFL NO. 1000 μm bare fiber 8800-00-0223 POF Universal, HP-HFBR-45XX 8800-00-0271PR 7 OFS300-200 and VS300 Inspection Scopes Only Connector Adapters for OFS 300-200 and VS 300 Series Inspection Scopes IMAGE TYPE AFL NO. SC/APC 8800-00-0220 FC/APC 8800-00-0218 E-2000/APC 8800-00-0229 MTP ® /MPO (0°), typically MM 8800-00-0233 MTP ® /MPO (8o), typically SM 8800-00-0234 1.25 mm open Universal 8800-00-0236 IMAGE TYPE AFL NO. 2.5 mm open Universal 8800-00-0219 SMC (0°) 8800-00-0235 1.6 mm Ferrule (pin) 8800-00-0244 2.0 mm Ferrule (pin) 8800-00-0248 EC (Radiall) 8800-00-0227 1.25/2.5 mm Universal sliding (2-position) adapter 8800-00-0265 8 IMAGE TYPE AFL NO. FC BIPM-00-FC SC BIPM-00-SC ST BIPM-00-ST IMAGE TYPE AFL NO. FC adapter 2900-50-0002MR SC adapter 2900-50-0003MR Connector Adapters for the OFI-BIPM Power Meter Port SVA1 Optical Attenuator Connector Adapters IMAGE TYPE AFL NO. LC BIPM-00-LC 2.5 Universal BIPM-00-25 IMAGE TYPE AFL NO. ST adapter 2900-50-0004MR LC adapter 2900-50-0006MR Fiber Optic Inspection Adapter Tips Reference Guide www.AFLglobal.com or (800) 321-5298, (603) 528-7780 Revision 2018.05.15 © 2018, AFL, all rights reserved. Specifications are subject to change without notice.
