The XFM® 2RU patch panel is a rack mountable interconnect point specifically designed to manage dense fiber applications up to 144F. All XFM® panels are fully compatible with AFL's XFM® Optical Cassette, Poli-MOD, and WDM solutions.
a5f12cc9fb964aa9aad9e0d5ef1b94eb
© 2008, AFL, all rights reserved. PP-2-00165, Revision 3, 6.4.20 Specifications are subject to change without notice. AFLglobal.com | 800.235.3423 1 Optical Connectivity Fiber Management Rack-Mount Panels The Xpress Fiber Management (XFM) 2U patch panel is a rack mountable interconnect point specifically designed to manage dense fiber applications. Based on the LGX ® intermateability platform, the panel is fully compatible with AFL’s XFM Optical Cassette, Passive Optical Coupler Modules, and Poli-MOD ® solutions. This panel offers enhanced management of densities up to 144 fibers using MTP-LC XFM Optical Cassettes (24 fibers). Features • Steel construction • Textured black powder coat finish • Universal WECO/TIA 19"/23" rack compatibility • (6) LGX 118 adapter plate / module mounting positions • Slide-out tray with relief cut-outs for simplified connector access • Optional front door key lock for heightened protection of internal components Xpress Fiber Management ® (XFM) 2RU Patch Panel Ordering I nformation DESCRIPTION MODEL NUMBER AFL NO. Xpress Fiber Management 2U Patch Panel, Black, Empty XFM-2-U-B-0 FM002712-BE Accessories DESCRIPTION AFL NO. Kit, Lock, for CON/CNS Panels FM001318 Specifications DEPTH (A) IN INCHES WIDTH (B) IN INCHES HEIGHT (C) IN INCHES RACK UNITS CAPACITY UNLOADED WEIGHT 15.5 17 3.5 2 (6) LGX 118 15 lbs. Applications • Data Centers • Enterprise Networks • Telecommunications Closets • Central Offices / Headends LGX is a registered trademark of Furukawa Electric North America, Inc.
Features:
- Steel construction
- Textured black powder coat finish
- Universal WECO/TIA 19”/23” rack compatibility
- (6) LGX 118 adapter plate and module mounting positions
Applications:
- Data Centers
- Enterprise Networks
- Telecommunications Closets
The Xpress Fiber Management® (XFM®) 2U patch panel is a rack-mountable interconnect point specifically designed to manage dense fiber applications. Based on the LGX® intermateability platform, the panel is fully compatible with AFL's XFM® optical cassette, passive optical coupler modules and Poli-MOD solutions.
This panel offers enhanced management of densities up to 144 fibers using MTP-LC XFM® optical cassettes (24 fibers).
