COPPER CABLING SYSTEMS Product Line Reference Guide AFL Copper Products COPPER CABLING SYSTEMS Copper Cabling Systems AFL’s copper cabling systems are the best-in-class, providing superior performance and reliability. No matter what category of cabling you need AFL can assist. From Category 6 A to Category 6 and Category 5e you will find a solution fit for purpose in the most advanced networks. Both Unshielded and Shielded solutions are available depending upon your network requirements. The Category 6 A Unshielded solution meets ANEXT (Alien Cross-Talk) standards by design alleviating the need for in field testing, saving time and money. Product Line Reference Guide 1 Category 6 A Cable AFL’s range of Category 6 A cable has link and channel performance meeting internationally defined physical and electrical characteristics up to 500 MHz. This cable is suitable for indoor use in static applications in both horizontal and backbone cabling in a structured cabling system. PRODUCT DESCRIPTION Category 6 A U-UTP 4 Pair Copper Cable ORDERING INFORMATION PACKAGING AFLCABLE6A-BL Category 6A U-UTP 4 Pair Copper Cable, Blue 305 m reel AFLCABLE6A-BL-L Category 6A U-UTP 4 Pair Copper Cable LSZH, Blue 305 m reel AFLCABLE6A-GY Category 6A U-UTP 4 Pair Copper Cable, Grey 305 m reel Category 6 A F-UTP 4 Pair Copper Cable ORDERING INFORMATION PACKAGING AFLCABLE6AF-BL Category 6A F-UTP 4 Pair Copper Cable, Blue 305 m reel AFLCABLE6AF-BL-L Category 6A F-UTP 4 Pair Copper Cable LSZH, Blue 305 m reel AFLCABLE6AF-GY Category 6A F-UTP 4 Pair Copper Cable, Grey 305 m reel Category 6 A U-FTP 4 Pair Copper Cable ORDERING INFORMATION PACKAGING AFLCABLE6AS-BL Category 6A U-FTP 4 Pair Copper Cable, Blue 305 m reel Category 6 A Patch Panels PRODUCT DESCRIPTION VELOCITY ™ Patch Panels AFL’s VELOCITY ™ cabling solutions deliver outstanding system performance, surpassing the requirements of ISO, EIA/TIA and AS/NZ standards. Designed to provide the ultimate in throughput, the VELOCITY ™ solution provides the best link and channel performance available and the ultimate in long-term cabling plant value. ORDERING INFORMATION PACKAGING VEL-1RU-24C6AU Patch Panel Category 6A UTP 24 Port 1RU Kit VEL-1RU-24C6AS Patch Panel Category 6A Shielded 24 Port 1RU Kit VEL-1RU-48C6AS Patch Panel Category 6A Shielded 48 Port 1RU Kit VEL-1RU-24C6AS-A Patch Panel Category 6A Shielded 24 Port Angled 1RU Kit VEL-1RU-24C6AU-S Patch Panel Category 6A UTP 24 Port Staggered 1RU Kit VEL-1RU-24C6AS-S Patch Panel Category 6A Shielded 24 Port Staggered 1RU Kit Unloaded VEL-1RU-24UL Patch Panel 24 Port 1RU – Unloaded Each VEL-1RU-48UL Patch Panel 48 Port 1RU – Unloaded Each VEL-1RU-24UL-A Patch Panel 24 Port Angled 1RU – Unloaded Each VEL-1RU-24UL-S Patch Panel 24 Port Staggered 1RU – Unloaded Each Labelling and Cable Management VEL-1RU-CTRAY Cable Tray with Labelling 1RU – Front Mount Each COPPER CABLING SYSTEMS 2 Category 6 A Outlets PRODUCT DESCRIPTION Category 6 A UTP Outlet AFL’s Category 6 A outlets offer best-in-class component performance. These RJ45 outlets are available with both keystone and Clipsal mounting clips. The keystone mounting outlets are for use in AFL patch panels and surface mount boxes whilst the Clipsal mounting outlets fit directly into standard faceplates without the need for an adaptor. These outlets offer exceptional performance that exceed industry standards. Offering Universal T568A/B wiring and the option of tool or tool-less termination. ORDERING INFORMATION PACKAGING AFLC6AU-WH Outlet Category 6A UTP White Keystone Each AFLC6AU-BK Outlet Category 6A UTP Black Keystone Each AFLC6AU-WHC Outlet Category 6A UTP White Clipsal Mount Each AFLC6AU-BK8 Outlet Category 6A UTP Black Keystone Bag of 8 Category 6 A Shielded Outlet The AFL Category 6 A fully shielded outlet is component compliant with exceptional Alien Cross-Talk performance. The outlet has the option of both tool and tool-less termination. When used in a network with AFL’s cable and patch panels you can be assured of network performance exceeding 10 Gigabit. ORDERING INFORMATION PACKAGING AFLC6AS Outlet Category 6A Shielded Keystone Each Category 6 A Shielded Outlet (Side Entry) This outlet includes a cable management piece providing side entry. When used in a network with AFL’s cable and patch panels you can be assured of network performance exceeding 10 Gigabit. ORDERING INFORMATION PACKAGING BC6AFS Outlet Category 6A Shielded Keystone – Side Entry Each Product Line Reference Guide 3 Category 6 A Patchcords PRODUCT DESCRIPTION Patchcords Unshielded AFL have the ability to manufacture an extensive range of Category 6 A UTP patchcords. These can be configured to varying lengths and a large variety of colours. ORDERING INFORMATION PACKAGING AFL6Axxx-BU Patchcord Category 6A UTP Blue LSZH Each AFL6Axxx-GY Patchcord Category 6A UTP Grey LSZH Each AFL6Axxx-RD Patchcord Category 6A UTP Red LSZH Each AFL6Axxx-GN Patchcord Category 6A UTP Green LSZH Each AFL6Axxx-YL Patchcord Category 6A UTP Yellow LSZH Each AFL6Axxx-SP Patchcord Category 6A UTP Salmon LSZH Each x = length (eg. 010 = 1 m, 015 = 1.5 m) Patchcords Shielded AFL have the ability to manufacture an extensive range of Category 6 A shielded patchcords. These can be configured to varying lengths and a large variety of colours. ORDERING INFORMATION PACKAGING AFL6ASxxx-BU Patchcord Category 6A STP Blue Each AFL6ASxxx-GY Patchcord Category 6A STP Grey Each AFL6ASxxx-GN Patchcord Category 6A STP Green Each AFL6ASxxx-YL Patchcord Category 6A STP Yellow Each x = length (eg. 010 = 1 m, 015 = 1.5 m) Patchcords Reduced Diameter These reduced diameter patchcords reduce clutter and improve cable management. They are channel complainant to Category 6 A standards. ORDERING INFORMATION PACKAGING AFL6AxxxSM-GY Patchcord Category 6A F-UTP Reduced Diameter, Grey Each x = length (eg. 010 = 1 m, 015 = 1.5 m) Patchcords Traceable These patchcords can be traced with the use of the AFL tracer tool. The tracer tool projects light to the opposite end of the patchcord. ORDERING INFORMATION PACKAGING AFL6AxxxTR-GY Patchcord Category 6A F-UTP Traceable, Grey Each x = length (eg. 010 = 1 m, 015 = 1.5 m) Field Terminable Plug This Field Terminable Plug is a full shielded RJ45 with rotatable head that maintains adequate bending radius in restricted spaces. This tooless plug is the perfect solution for direct attachment to IP devices including IP cameras, IP access control and Wifi access points. ORDERING INFORMATION PACKAGING PLAG6AFS Full shielded angled RJ45 plug Each Pre-terminated Cable Assemblies PRODUCT DESCRIPTION VELOCITY™ Pre-terminated Cable Assemblies AFL offers fully pre-terminated and factory tested copper cabling solution for Category 6 A shielded networks. AFL offers the flexibility to have one end or both ends terminated for use in cross connects, or consolidation points. ORDERING INFORMATION PACKAGING VEL-1RU-24UL Patch Panel 24 Port 1RU Unloaded Each VEL-1RU-24UL-A Patch Panel 24 Port 1RU Angled Unloaded Each BU/PK = Blue/Pink (for Defence) 6AFTP = Cat6A F-UTP Length (m) xx = meters RJB = RJ45 Bundle RJBP = RJ45 Bundle Pigtail RJB 6AFTP XX COPPER CABLING SYSTEMS 4 Category 6 Cable PRODUCT DESCRIPTION Category 6 U-UTP 4 Pair Copper Cable AFL’s Category 6 cable is amongst the best performers on the market today. Its improved crosstalk and attenuation performance make it ideal for the most advanced networks. It is perfectly matched to AFL’s Category 6 outlets and patch panels guaranteeing exceptional network performance well into the future. ORDERING INFORMATION PACKAGING AFLCABLE6U-GY Category 6 U-UTP Cable, Grey Box 305 m AFLCABLE6U-BL-L Category 6 U-UTP Cable, Blue LSZH Box 305 m AFLCABLE6U-BK-L Category 6 U-UTP Cable, Black LSZH Box 305 m AFLCABLE6U-PK-L Category 6 U-UTP Cable, Pink LSZH Box 305 m AFLCABLE6U-WH-L Category 6 U-UTP Cable, White LSZH Box 305 m Category 6 Patch Panels PRODUCT DESCRIPTION VELOCITY ™ Patch Panels AFL’s VELOCITY ™ cabling solutions deliver outstanding system performance, surpassing the requirements of ISO, EIA/TIA and AS/NZ standards. Designed to provide the ultimate in throughput, the VELOCITY ™ solution provides the best link and channel performance available and the ultimate in long-term cabling plant value. AFL’s VELOCITY ™ cabling systems integrate seamlessly with our INFINITY ™ Fibre Cabling solutions making AFL your one stop communications specialist. ORDERING INFORMATION PACKAGING AFL24/6U Patch Panel 24 Port Category 6 UTP Each VEL-1RU-24C6U Patch Panel Category 6 UTP 24 Port 1RU Kit VEL-1RU-48C6U Patch Panel Category 6 UTP 48 Port 1RU Kit VEL-1RU-24C6U-A Patch Panel Category 6 UTP 24 Port Angled 1RU Kit VEL-1RU-24C6U-S Patch Panel Category 6 UTP 24 Port Staggered 1RU Kit Unloaded VEL-1RU-24UL Patch Panel 24 Port 1RU – Unloaded Each VEL-1RU-48UL Patch Panel 48 Port 1RU – Unloaded Each VEL-1RU-24UL-A Patch Panel 24 Port Angled 1RU – Unloaded Each VEL-1RU-24UL-S Patch Panel 24 Port Staggered 1RU – Unloaded Each Labelling and Cable Management VEL-1RU-CTRAY Cable Tray with Labelling 1RU – Front Mount Each Category 6 Outlets PRODUCT DESCRIPTION Category 6 U-UTP Outlet AFL’s Category 6 outlets offer best-in-class Category 6 component performance. These RJ45 outlets are available with both keystone and Clipsal mounting clips. The keystone mounting outlets are for use in AFL patch panels and surface mount boxes whilst the Clipsal mounting outlets fit directly into standard faceplates without the need for an adaptor. These outlets offer exceptional performance that exceed industry standards. Offering Universal T568A/B wiring and the option of tool or tool-less termination. ORDERING INFORMATION PACKAGING AFLC6U-WH Outlet Category 6 UTP White Keystone Each AFLC6U-BK Outlet Category 6 UTP Black Keystone Each AFLC6U-WHC Outlet Category 6 UTP White Clipsal Mount Each AFLC6U-BK8 Outlet Category 6 UTP Black Keystone Bag of 8 Product Line Reference Guide 5 Category 6 Patchcords PRODUCT DESCRIPTION Patchcords Unshielded AFL Category 6 patchcords are component compliant and are 100% tested. They feature a latch protector and strain relief and are available in a variety of colours and lengths. ORDERING INFORMATION PACKAGING AFL6XXX-GY Patchcord Category 6 UTP Grey Each AFL6XXX-BU Patchcord Category 6 UTP Blue Each AFL6XXX-GN Patchcord Category 6 UTP Green Each AFL6XXX-YL Patchcord Category 6 UTP Yellow Each Replace XXX with length (eg: 010 = 1 m, 015 = 1.5 m) Patchcords Reduced Diameter These reduced diameter patchcords reduce clutter and improve cable management. They are channel complainant to Category 6 standards. ORDERING INFORMATION PACKAGING AFL6xxxSM-GY Patchcord Category 6 U-UTP Reduced Diameter, Grey Each AFL6xxxSM-BU Patchcord Category 6 U-UTP Reduced Diameter, Blue Each x = length (eg. 010 = 1 m, 015 = 1.5 m) Pre-terminated Cable Assemblies PRODUCT DESCRIPTION VELOCITY™ Pre-terminated Cable Assemblies AFL offers fully pre-terminated and factory tested copper cabling solutions for Category 6 unshielded networks. AFL offers the flexibility to have one end or both ends terminated for use in cross connects, or consolidation points. ORDERING INFORMATION VEL-1RU-24UL Patch Panel 24 Port 1RU Unloaded Each VEL-1RU-24UL-A Patch Panel 24 Port 1RU Angled Unloaded Each BU/PK = Blue/Pink (for Defence) 6UTP = Cat 6 UTP Length (m) xx = meters RJB = RJ45 Bundle RJBP = RJ45 Bundle Pigtail RJB 6UTP XX COPPER CABLING SYSTEMS 6 Category 5e Cable PRODUCT DESCRIPTION Category 5e U-UTP 4 Pair Copper Cable This range of unscreened cables is designed to support Cat 5 Enhanced link and channel performance. ORDERING INFORMATION PACKAGING AFLCABLE5U-GY Cable Category 5e U-UTP Grey Box 305 m AFLCABLE5U-BL Cable Category 5e U-UTP Blue Box 305 m Category 5e Patch Panels PRODUCT DESCRIPTION VELOCITY ™ Patch Panels AFL’s VELOCITY ™ cabling solutions provides the best link and channel performance available and the ultimate in long-term cabling plant value. ORDERING INFORMATION PACKAGING AFL24/5EU Patch Panel 24 Port Category 5e UTP Kit Unloaded VEL-1RU-24UL Patch Panel 24 Port 1RU – Unloaded Each VEL-1RU-48UL Patch Panel 48 Port 1RU – Unloaded Each VEL-1RU-24UL-A Patch Panel 24 Port Angled 1RU – Unloaded Each Labelling and Cable Management VEL-1RU-CTRAY Cable Tray with Labelling 1RU – Front Mount Each Category 5e Outlets PRODUCT DESCRIPTION Category 5e U-UTP Outlet AFL’s Category 5e RJ45 outlets are available with both keystone and Clipsal mounting clips. The keystone mounting outlets are for use in AFL patch panels and surface mount boxes whilst the Clipsal mounting outlets fit directly into standard faceplates without the need for an adaptor. Offering Universal T568A/B wiring and have the option of tool or tool-less termination. ORDERING INFORMATION PACKAGING AFLC5U-WH Outlet Category 5e UTP White Keystone Each AFLC5U-BK Outlet Category 5e UTP Black Keystone Each AFLC5U-WHC Outlet Category 5e UTP White Clipsal Mount Each Category 5e Patchcords PRODUCT DESCRIPTION Patchcords AFL’s Category 5e patch and workstation cords are the perfect complement to any copper cabling system. AFL’s Category 5e patchcords offer a strain-relief solution that ensures stability during and after adds, moves or changes. ORDERING INFORMATION Connector sub-type S – Snagless Otherwise leave blank Cable configuration UTP – Unterminated Twisted Pair STP – Shielded Twisted Pair FTP – Foil Twisted Pair SOL – Solid Length (m) Cable Colour AQ – Aqua BK – Black BU – Blue BR – Brown GN – Green GY – Grey OR – Orange PK – Pink SP – Salmon pink PL – Purple RD – Red WH – White YL – Yellow Cable Type 5E – Cat 5 Enhanced Connector type RJ12 – RJ12 connector RJ – RJ45 connector 110 – 110 connector — RJ S 5E UTP 1M GN Product Line Reference Guide 7 Secure Locking Keyed RJ45 Connectors, Cable Assemblies and Accessories The Secure RJ cable assemblies and matching extraction tools are available in eight key ways and colors. White patchcord cable is standard. Red and blue cable colours as well as shielded patchcords can also be supplied upon request. To complement the SRJ connectors, AFL provides the Secure RJ Locking Port Plugs acting as ‘locking dust caps’. This enables empty RJ ports to be locked out preventing the unauthorised insertion of cable assemblies or connectors. The port plugs can be disconnected the same way as the SRJ connector by simply using the appropriately keyed extraction tool. Cable Assembly Part Number Conguration SRJ Keyed Extraction Tools SRJ Port Blockers Secure RJ Component Part Numbers KEY HOUSING COLOUR PORT BLOCKER P/NO EXTRACTION TOOL P/NO Black SRJPB-BK SRJET-BK Yellow SRJPB-Y SRJET-Y Orange SRJPB-O SRJET-O Red SRJPB-R SRJET-R Blue SRJPB-B SRJET-B Green SRJPB-G SRJET-G Purple SRJPB-P SRJET-P Admin N/A SRJET-A Cable Type C6 – CAT6 C6A - CAT6a End A Housing Key BK – Black C – Clear Y – Yellow O – Orange R – Red B – Blue G – Green P – Purple PT – Pigtail End B Housing Key BK – Black C – Clear Y – Yellow O – Orange R – Red B – Blue G – Green P – Purple PT – Pigtail Length (m) Cable Colour W – white SRJ — — — — — C6 W Y Y XM COPPER CABLING SYSTEMS 8 Surface Mount Boxes PRODUCT DESCRIPTION PART NUMBER PACKAGING Surface Mount Box 1 Port AFL’s Surface Mount Boxes are a low-profile, workstation solution that offers flexibility for multiple network configurations. Complete with colour coded ICONs and shutters to protect the outlet when not in use. AFLSMB1 Each Surface Mount Box 2 Port AFL’s Surface Mount Boxes are a low-profile, workstation solution that offers flexibility for multiple network configurations. Complete with colour coded ICONs and shutters to protect the outlet when not in use. AFLSMB2 Each Surface Mount Box 4 Port AFL’s Surface Mount Boxes are a low-profile, workstation solution that offers flexibility for multiple network configurations. Complete with colour coded ICONs and shutters to protect the outlet when not in use. AFLSMB4 Each Surface Mount Box 6 Port AFL’s Surface Mount Boxes are a low-profile, workstation solution that offers flexibility for multiple network configurations. Complete with colour coded ICONs and shutters to protect the outlet when not in use. AFLSMB6 Each MUTO-6/12 Port The MUTO box has the flexibility of being configured with either 6 or 12 ports and provides extra cable management room within the box. AFLSMB6-MUTO Each Tools PRODUCT DESCRIPTION PART NUMBER PACKAGING RJ45 Termination Tool Termination tool used on all categories of Keystone Outlets. Terminates and trims all 8 wires (4 pairs) at once. (Note: Cannot be used on Clipsal mount outlets or side entry outlets). AFLRJTOOL Each Patchcord Tracer Tool This tool lights up the ends of a patchcord for easy port identification. AFLPCTRACER Each Impact Punch Down Tool Impact Punch Down Tool for Type 110 Connector AFLPA3572 Each Replacement Bit for AFLPA3572 AFLPA4572 Each Product Line Reference Guide 9 Cable Management PRODUCT DESCRIPTION PART NUMBER PACKAGING Horizontal Patchcord Minder 1RU One rack unit patchcord minder with 4 large clips that rotate into both horizontal and vertical locations. FRE-1RU-PCMNDR Each Patchcord Minder 1RU Finger Style One rack unit patchcord minder with flexible fingers and clip on cover. AFLCM1RU Each Patchcord Minder 2RU Finger Style Two rack unit patchcord minder with flexible fingers and clip on cover. AFLCM2RU Each Patchcord Minder 1RU Brush Style One rack unit brush strip that assists with patchcord management. AFLCMBRUSH Each Bezels PRODUCT DESCRIPTION Keystone/ Clipsal Bezels These Bezels are used for mounting keystone jacks into Clipsal faceplates. ORDERING INFORMATION PACKAGING AFLBEZEL-WH Keystone to Clipsal Bezel, White Bag of 10 AFLBEZEL-BK Keystone to Clipsal Bezel, Black Bag of 10 AFLBEZEL-PK Keystone to Clipsal Bezel, Pink Bag of 10 AFLBEZEL-BU Keystone to Clipsal Bezel, Blue Bag of 10 AFLBEZEL-GY Keystone to Clipsal Bezel, Grey Bag of 10 AFLBEZEL-RD Keystone to Clipsal Bezel, Red Bag of 10 Unloaded Panels PRODUCT DESCRIPTION PART NUMBER PACKAGING Patch Panel 24 Port Unloaded 24 port keystone patch panel with rear cable management. This panel can be used with any category of AFL outlets. AFL24UL-BK Each Patch Panel 24 Port Unloaded Angled 24 port keystone patch panel with rear cable management. This angled panel can be used with any category of AFL outlets. Provides improved cable management with the patchcords being directed to the side of the cabinet. AFL24ULV-BK Each Velocity 32 Port Muto Unloaded 32 Port MUTO providing flexibility in horizontal cabling systems. This can be used with any category of AFL outlets. VEL-MUTO32 Each AFL Copper Products ANZ Head Office 93-97 Merrindale Drive Croydon South VIC 3136 AUSTRALIA TEL: +61 3 9737 4200 Cable Manufacturing 100 Olympia Street Tottenham VIC 3012 AUSTRALIA TEL: +61 9316 8300 Sydney 13/14 Boden Road Seven Hills NSW 2147 AUSTRALIA TEL: +61 2 9421 4200 Newcastle TEL: +61 416 652 749 Brisbane 2/50 Borthwick Avenue Murarrie QLD 4172 AUSTRALIA TEL: +61 7 3292 1400 Perth 1/4 Camden Street Belmont WA 6104 AUSTRALIA TEL: +61 8 6253 2200 Canberra 17/15-21 Beaconsfield Street Fyshwick ACT 2609 AUSTRALIA TEL: +61 2 6143 2300 Adelaide 1/151-153 Gilles Street Adelaide SA 5000 AUSTRALIA TEL: +61 8 8198 8802 Auckland 8/11 Orbit Drive Rosedale, North Shore Auckland 0632 NEW ZEALAND TEL: +64 9 927 7140 1300 232 476 | AFLglobal.com © 2018 AFL, all rights reserved. 1199 v2 10.2018
