19 © 2008, AFL, all rights reserved PP-4-00037, Revision 6 , 4 14 16 Specifications are subject to change without notice The AutoCleaver S2 contains special fiber clamps with air pressure-controlled clamping forces, designed for cleaving air-clad fiber Coupled with modified software, these features enable the AutoCleaver S2 to handle otherwise difficult-to-cleave fibers The clamping force of the fiber clamps is set individually by changing the air pressure Specifications PARAMETER VALUE Fiber Cladding 125 - 1000 μm* Fiber Coating 250 - 1500 μm* Cycle Time Typical < 14 seconds Cleave Angle Typical < 0 5º Fiber Waste Typical < 20 mm Power Supply External 12V DC Compressed Air 4mm instant push-in fitting PC Connection RS-232 Dimensions 175 mm(W) x 138 mm(D) x 104 mm(H) Weight 2 5 kg * Fiber specific handling kits required Features • Fully automatic • Low cleave angles of < 0 5º • Very flat end faces • Operator independent • Automatic fiber waste collection • Long-lasting diamond • PC controllable AutoCleaver S2 Ordering Information DESCRIPTION AFL NO. AutoCleaver S2 - Small Cylinder/FJK Includes: 12 mm v-groove clamping cylinder, FJK Fiber Holder Adapter LDF, RS-232 cable, PC software, tools and manuals 50100030 AutoCleaver S2 - Large Cylinder/FJK Includes: 20 mm v-groove clamping cylinder, FJK Fiber Holder Adapter LDF, RS-232 cable, PC software, tools and manuals 50100092 Accessories DESCRIPTION LABEL AFL NO. V-groove, STD, Cladding 125-199 μm Yellow 51030020 V-groove, LD, Cladding 200-349 μm Orange 50100086 V-groove, LD, Cladding 350-699 μm Green 50100087 V-groove, LD, Cladding 700-1000 μm Red 50100088 Height Adjuster LD, Cladding 200-349 μm Orange 50100048 Height Adjuster LD, Cladding 350-529 μm White 50100049 Height Adjuster LD, Cladding 530-699 μm Black 50100050 Height Adjuster LD, Cladding 700-1000 μm Red 50100051 Holder, LD, Coating 200-299 μm 250 μm 50100059 Holder, LD, Coating 300-399 μm 350 μm 50100060 Holder, LD, Coating 400-499 μm 450 μm 50100061 Holder, LD, Coating 500-599 μm 550 μm 50100062 Holder, LD, Coating 600-699 μm 650 μm 50100063 Holder, LD, Coating 700-799 μm 750 μm 50100064 Holder, LD, Coating 800-899 μm 850 μm 50100065 Holder, LD, Coating 900-999 μm 950 μm 50100066 Holder, LD, Coating 1000-1099 μm 1050 μm 50100054 Holder, LD, Coating 1100-1199 μm 1150 μm 50100055 Holder, LD, Coating 1200-1299 μm 1250 μm 50100056 Holder, LD, Coating 1300-1399 μm 1350 μm 50100057 Holder, LD, Coating 1400-1499 μm 1450 μm 50100058 Distance Plate LD Cladding 200-349 μm Orange 50100034 Distance Plate LD Cladding 350-699 μm Green 50100035 Distance Plate LD Cladding 700-1000 μm Red 50100036 Diamond blade — 50100091 Cleaver Blade Replacement Tool — 50100032 Power Supply, 100-240 V, 1 25 A — 50100075 Adapter for Power Supply, US — 50100009
