www.AFLglobal.com or 800-866-7385 © 2003, AFL, all rights reserved. PP-3-00747, Revision 6, 9.13.16 Specifications are subject to change without notice. 297 HiTemp ® ACSS ACCESSORIES Step 1: Catalog Number Determine the assembly catalog number based on the conductor being used Step 2: Extra High Voltage Finish For Extra High Voltage Finish, use "EHV" ( > 345 kV) For Standard Finish, leave blank (< 345 kV) Step 3: Assemble Catalog Number Example: For 795 Drake ACSS Conductor with an EHV finish, the complete catalog number is: 5630.116HTEHV The 5600HT Series Straight Terminal Connector is specifically designed for ACSS conductors It is fabricated from a specially tempered aluminum that will transfer elevated current and dissipate increased heat more efficiently All HiTemp Terminal Connectors are designed for limited tension use, maintaining a minimum of 40% of the ASTM rated strength of the conductor Square edges of the compression accessory pad can cause Corona Pads with rounded edges and corners can be supplied by adding the catalog suffix ‘EHV’ Ordering Instructions HiTemp Connector for ACSS Conductor, Straight, 5600HT Series Catalog Number EHV Finish + Notes: 1 Pad Dimensions are on page 339 2 HiTemp AFL Filler Compound (AFCHT) Requirements are on page 340 3 Bolt Sizes and Torque Recommendations are on page 340 4 Installation Instructions for Terminals are on page 351 5 For more information on die selction and ordering instructions, see the Tools and Equipment section of this catalog Catalog Number Conductor Die Size Weight Total Length L Pad Size Code Name Size Stranding Diameter kcmil Al/St in lbs kg in mm 5676 688HT Partridge/ACSS 266 8 26/7 0 642 76AH 0 6 0 3 8 6 218 D 5620 781HT Woodcock/ACSS 336 4 22/7 0 701 20AH 0 6 0 3 8 9 226 D 5620 812HT Linnet/ACSS 336 4 26/7 0 720 20AH 0 6 0 3 8 9 226 D 5620 781HT Oriole/ACSS 336 4 30/7 0 741 20AH 0 6 0 3 8 9 226 D 5620 812HT Ptarmigan/ACSS 397 5 20/7 0 752 20AH 0 6 0 3 8 9 226 D 5620 812HT Brant/ACSS 397 5 24/7 0 772 20AH 0 6 0 3 8 9 226 D 5620 844HT Ibis/ACSS 397 5 26/7 0 783 20AH 0 6 0 3 8 9 226 D 5620 844HT Lark/ACSS 397 5 30/7 0 806 20AH 0 6 0 3 8 9 226 D 5620 875HT Tailorbird/ACSS 477 0 20/7 0 823 20AH 0 6 0 3 9 6 244 D 5624 938HT Flicker/ACSS 477 0 24/7 0 846 24AH 1 0 0 4 9 6 244 D 5624 938HT Hawk/ACSS 477 0 26/7 0 858 24AH 1 0 0 4 9 6 244 D 5624 938HT Hen/ACSS 477 0 30/7 0 883 24AH 1 0 0 4 9 6 244 D 5624 969HT Sapsucker/ACSS 556 5 22/7 0 901 24AH 1 0 0 4 9 6 244 D 5624 969HT Parakeet/ACSS 556 5 24/7 0 914 24AH 1 0 0 4 9 6 244 D 5627 100HT Dove/ACSS 556 5 26/7 0 927 27AH 2 2 1 0 17 1 434 D 5627 100HT Eagle/ACSS 556 5 30/7 0 953 27AH 2 2 1 0 17 1 434 D 5627 100HT Peacock/ACSS 605 0 24/7 0 953 27AH 2 2 1 0 17 1 434 D 5627 100HT Squab/ACSS 605 0 26/7 0 966 27AH 2 2 1 0 17 1 434 D 5627 106HT Wood Duck/ACSS 605 0 30/7 0 994 27AH 2 2 1 0 17 1 434 D 5627 106HT Teal/ACSS 605 0 30/19 0 994 27AH 2 2 1 0 17 1 434 D 5627 106HT Goldfinch/ACSS 636 0 22/7 0 963 27AH 2 2 1 0 17 1 434 D www.AFLglobal.com or 800-866-7385 © 2003, AFL, all rights reserved. PP-3-00747, Revision 6, 9.13.16 Specifications are subject to change without notice. 298 HiTemp ® ACSS ACCESSORIES HiTemp Connector for ACSS Conductor, Straight, 5600HT Series (cont.) Catalog Number Conductor Die Size Weight Total Length L Pad Size Code Name Size Stranding Diameter kcmil Al/St in lbs kg in mm 5627 106HT Rook/ACSS 636 0 24/7 0 977 27AH 2 2 1 0 17 1 434 D 5627 106HT Grosbeak/ACSS 636 0 26/7 0 990 27AH 2 2 1 0 17 1 434 D 5627 106HT Scoter/ACSS 636 0 30/7 1 019 27AH 2 2 1 0 17 1 434 D 5627 106HT Egret/ACSS 636 0 30/19 1 019 27AH 2 2 1 0 17 1 434 D 5627 106HT Flamingo/ACSS 666 6 24/7 1 000 27AH 2 2 1 0 17 1 434 D 5627 106HT Gannet/ACSS 666 6 26/7 1 014 27AH 2 2 1 0 17 1 434 D 5630 109HT Stilt/ACSS 715 5 24/7 1 036 30AH 3 1 1 4 18 3 465 D 5630 116HT Starling/ACSS 715 5 26/7 1 051 30AH 2 9 1 3 18 5 471 D 5360 116HT Redwing/ACSS 715 5 30/19 1 081 30AH 2 9 1 3 18 5 471 D 5630 116HT Cuckoo/ACSS 795 0 24/7 1 092 30AH 2 9 1 3 18 5 471 D 5630 122HT Drake/ACSS 795 0 26/7 1 108 30AH 2 9 1 3 18 5 471 D 5630 116HT Macaw/ACSS 795 0 42/7 1 055 30AH 2 9 1 3 18 5 471 D 5630 116HT Tern/ACSS 795 0 45/7 1 063 30AH 2 9 1 3 18 5 471 D 5630 116HT Condor/ACSS 795 0 54/7 1 092 30AH 2 9 1 3 18 5 471 D 5630 122HT Mallard/ACSS 795 0 30/19 1 140 30AH 2 8 1 3 18 7 476 D 5630 122HT Ruddy/ACSS 900 0 45/7 1 131 30AH 2 8 1 3 18 7 476 D 5630 122HT Canary/ACSS 900 0 54/7 1 162 30AH 2 8 1 3 18 7 476 D 5630 125HT Corncrake/ACSS 954 0 20/7 1 165 30AH 2 8 1 3 18 8 477 D 5630 125HT Redbird/ACSS 954 0 24/7 1 196 30AH 2 8 1 3 18 8 477 D 5630 122HT Rail/ACSS 954 0 45/7 1 165 30AH 2 8 1 3 18 8 477 D 5630 125HT Towhee/ACSS 954 0 48/7 1 175 30AH 2 8 1 3 18 8 477 D 5630 125HT Cardinal/ACSS 954 0 54/7 1 196 30AH 2 8 1 3 18 8 477 D 5634 134HT Canvasback/ACSS 954 0 30/19 1 248 34AH 4 0 1 8 19 7 500 D 5634 128HT Snowbird/ACSS 1033 5 42/7 1 203 34AH 4 2 1 9 19 3 500 D 5634 134HT Ortolan/ACSS 1033 5 45/7 1 212 34AH 4 0 1 8 19 7 500 D 5634 134HT Curlew/ACSS 1033 5 54/7 1 245 34AH 4 0 1 8 19 7 500 D 5634 134HT Bluejay/ACSS 1113 0 45/7 1 259 34AH 4 0 1 8 19 7 500 D 5634 138HT Finch/ACSS 1113 0 54/19 1 293 34AH 4 0 1 8 20 0 508 D 5634 138HT Bunting/ACSS 1192 5 45/7 1 302 34AH 4 0 1 8 20 0 508 D 5636 144HT Grackle/ACSS 1192 5 54/19 1 338 36AH 4 5 2 0 20 5 522 D 5636 144HT Bittern/ACSS 1272 0 45/7 1 345 36AH 4 5 2 0 20 5 522 D 5636 144HT Diver/ACSS 1272 0 48/7 1 357 36AH 4 5 2 0 20 5 522 D 5636 147HT Pheasant/ACSS 1272 0 54/19 1 382 36AH 4 4 2 0 20 1 511 D 5636 147HT Dipper/ACSS 1351 5 45/7 1 386 36AH 4 4 2 0 20 1 511 D 5638 156HT Martin/ACSS 1351 5 54/19 1 424 38AH 5 1 2 4 21 8 555 D 5638 150HT Bobolink/ACSS 1431 0 45/7 1 427 38AH 5 4 2 4 21 1 536 D 5638 156HT Plover/ACSS 1431 0 54/19 1 465 38AH 5 1 2 3 21 8 555 D 5638 156HT Nuthatch/ACSS 1510 0 45/7 1 466 38AH 5 1 2 3 21 8 555 D 5640 162HT Parrot/ACSS 1510 0 54/19 1 505 40AH 5 9 2 7 22 5 572 E 5640 162HT Ratite/ACSS 1590 0 42/7 1 492 40AH 5 9 2 7 22 5 572 E 5640 162HT Lapwing/ACSS 1590 0 45/7 1 504 40AH 5 9 2 7 22 5 572 E 5640 162HT Falcon/ACSS 1590 0 54/19 1 544 40AH 5 9 2 7 22 5 572 E 5642 178HT Chukar/ACSS 1780 0 84/19 1 602 42AH 6 4 2 9 23 0 584 E 5642 178HT Mockingbird/ACSS 2034 5 72/7 1 681 42AH 6 4 2 9 23 0 584 E 5642 178HT Roadrunner/ACSS 2057 0 76/19 1 700 42AH 6 4 2 9 23 0 584 E 5644 184HT Bluebird/ACSS 2156 0 84/19 1 762 44AH 7 5 3 4 23 5 598 E 5644 181HT Kiwi/ACSS 2167 0 72/7 1 735 44AH 7 5 3 4 23 5 598 E 5644 188HT Thrasher/ACSS 2312 0 76/19 1 802 44AH 7 5 3 4 23 5 598 E 5648 197HT Joree/ACSS 2515 0 76/19 1 880 48AH 8 7 4 0 25 6 650 E www.AFLglobal.com or 800-866-7385 © 2003, AFL, all rights reserved. PP-3-00747, Revision 6, 9.13.16 Specifications are subject to change without notice. 299 HiTemp ® ACSS ACCESSORIES Step 1: Catalog Number Determine the assembly catalog number based on the conductor being used Step 2: Extra High Voltage Finish For Extra High Voltage Finish, use "EHV" ( > 345 kV) For Standard Finish, leave blank (< 345 kV) Step 3: Assemble Catalog Number Example: For 795 Drake ACSS Conductor with an EHV finish, the complete catalog number is: 5130.116HTEHV The 5100HT Series 15º Terminal Connector is specifically designed for ACSS conductors It is fabricated from a specially tempered aluminum that will transfer elevated current and dissipate increased heat more efficiently When used with the HiTemp Dead End, the 15º terminal connector can be bolted in either the straight or 30º position All HiTemp Terminal Connectors are designed for limited tension use, maintaining a minimum of 40% of the ASTM rated strength of the conductor Aluminum hardware is supplied with the 15º terminal connector Square edges of the compression accessory pad can cause Corona Pads with rounded edges and corners can be supplied by adding the catalog suffix ‘EHV’ Ordering Instructions HiTemp Terminal Connector for ACSS Conductor, 1 5º, 5 1 00HT Series Catalog Number EHV Finish + Notes: 1 Pad Dimensions are on page 339 2 HiTemp AFL Filler Compound (AFCHT) Requirements are on page 340 3 Bolt Sizes and Torque Recommendations are on page 340 4 Installation Instructions for Terminals are on page 351 5 For more information on die selction and ordering instructions, see the Tools and Equipment section of this catalog Catalog Number Conductor Die Size Weight Total Length L Pad SIze Code Name Size Stranding Diameter kcmil Al/St in lbs kg in mm 5176 688HT Partridge/ACSS 266 8 26/7 0 642 76AH 1 6 0 7 13 1 333 D 5120 781HT Woodcock/ACSS 336 4 22/7 0 701 20AH 1 6 0 7 13 2 335 D 5120 812HT Linnet/ACSS 336 4 26/7 0 720 20AH 1 6 0 7 13 2 335 D 5120 781HT Oriole/ACSS 336 4 30/7 0 741 20AH 1 6 0 7 13 2 335 D 5120 812HT Ptarmigan/ACSS 397 5 20/7 0 752 20AH 1 6 0 7 13 2 335 D 5120 812HT Brant/ACSS 397 5 24/7 0 772 20AH 1 6 0 7 13 2 335 D 5120 844HT Ibis/ACSS 397 5 26/7 0 783 20AH 1 6 0 7 13 2 335 D 5120 844HT Lark/ACSS 397 5 30/7 0 806 20AH 1 6 0 7 13 2 335 D 5120 875HT Tailorbird/ACSS 477 0 20/7 0 823 20AH 1 7 0 8 14 0 356 D 5124 938HT Flicker/ACSS 477 0 24/7 0 846 24AH 2 0 0 9 13 9 353 D 5124 938HT Hawk/ACSS 477 0 26/7 0 858 24AH 2 0 0 9 13 9 353 D 5124 938HT Hen/ACSS 477 0 30/7 0 883 24AH 2 0 0 9 13 9 353 D 5124 969HT Sapsucker/ACSS 556 5 22/7 0 901 24AH 2 0 0 9 13 9 353 D 5124 969HT Parakeet/ACSS 556 5 24/7 0 914 24AH 2 0 0 9 13 9 353 D 5127 100HT Dove/ACSS 556 5 26/7 0 927 27AH 2 5 1 1 16 3 414 D 5127 100HT Eagle/ACSS 556 5 30/7 0 953 27AH 2 5 1 1 16 3 414 D 5127 100HT Peacock/ACSS 605 0 24/7 0 953 27AH 2 5 1 1 16 3 414 D 5127 100HT Squab/ACSS 605 0 26/7 0 966 27AH 2 5 1 1 16 3 414 D 5127 106HT Wood Duck/ACSS 605 0 30/7 0 994 27AH 2 4 1 1 16 3 414 D 5127 106HT Teal/ACSS 605 0 30/19 0 994 27AH 2 4 1 1 16 3 414 D 5127 106HT Goldfinch/ACSS 636 0 22/7 0 963 27AH 2 5 1 1 16 3 414 D www.AFLglobal.com or 800-866-7385 © 2003, AFL, all rights reserved. PP-3-00747, Revision 6, 9.13.16 Specifications are subject to change without notice. 300 HiTemp ® ACSS ACCESSORIES Catalog Number Conductor Die Size Weight Total Length L Pad SIze Code Name Size Stranding Diameter kcmil Al/St in lbs kg in mm 5127 106HT Rook/ACSS 636 0 24/7 0 977 27AH 2 4 1 1 16 3 414 D 5127 106HT Grosbeak/ACSS 636 0 26/7 0 990 27AH 2 4 1 1 16 3 414 D 5127 106HT Scoter/ACSS 636 0 30/7 1 019 27AH 2 4 1 1 16 3 414 D 5127 106HT Egret/ACSS 636 0 30/19 1 019 27AH 2 4 1 1 16 3 414 D 5127 106HT Flamingo/ACSS 666 6 24/7 1 000 27AH 2 4 1 1 16 3 414 D 5127 106HT Gannet/ACSS 666 6 26/7 1 014 27AH 2 4 1 1 16 3 414 D 5130 109HT Stilt/ACSS 715 5 24/7 1 036 30AH 3 4 1 5 17 5 445 D 5130 116HT Starling/ACSS 715 5 26/7 1 051 30AH 3 3 1 5 17 8 452 D 5130 116HT Redwing/ACSS 715 5 30/19 1 081 30AH 3 3 1 5 17 8 452 D 5130 116HT Cuckoo/ACSS 795 0 24/7 1 092 30AH 3 3 1 5 17 8 452 D 5130 122HT Drake/ACSS 795 0 26/7 1 108 30AH 3 3 1 5 17 8 452 D 5130 116HT Macaw/ACSS 795 0 42/7 1 055 30AH 3 3 1 5 17 8 452 D 5130 116HT Tern/ACSS 795 0 45/7 1 063 30AH 3 3 1 5 17 8 452 D 5130 116HT Condor/ACSS 795 0 54/7 1 092 30AH 3 3 1 5 17 8 452 D 5130 122HT Mallard/ACSS 795 0 30/19 1 140 30AH 3 1 1 4 18 1 460 D 5130 122HT Ruddy/ACSS 900 0 45/7 1 131 30AH 3 1 1 4 18 1 460 D 5130 122HT Canary/ACSS 900 0 54/7 1 162 30AH 3 1 1 4 18 1 460 D 5130 122HT Corncrake/ACSS 954 0 20/7 1 165 30AH 3 1 1 4 18 1 460 D 5130 125HT Redbird/ACSS 954 0 24/7 1 196 30AH 3 1 1 4 18 3 465 D 5130 122HT Rail/ACSS 954 0 45/7 1 165 30AH 3 1 1 4 18 1 460 D 5130 125HT Towhee/ACSS 954 0 48/7 1 175 30AH 3 1 1 4 18 3 465 D 5130 125HT Cardinal/ACSS 954 0 54/7 1 196 30AH 3 1 1 4 18 3 465 D 5134 134HT Canvasback/ACSS 954 0 30/19 1 248 34AH 4 4 2 0 18 3 465 D 5134 128HT Snowbird/ACSS 1033 5 42/7 1 203 34AH 4 5 2 0 18 1 460 D 5134 134HT Ortolan/ACSS 1033 5 45/7 1 212 34AH 4 4 2 0 18 3 465 D 5134 134HT Curlew/ACSS 1033 5 54/7 1 245 34AH 4 4 2 0 18 3 465 D 5134 134HT Bluejay/ACSS 1113 0 45/7 1 259 34AH 4 4 2 0 18 3 465 D 5134 138HT Finch/ACSS 1113 0 54/19 1 293 34AH 4 2 1 9 18 4 467 D 5134 138HT Bunting/ACSS 1192 5 45/7 1 302 34AH 4 2 1 9 18 4 467 D 5136 144HT Grackle/ACSS 1192 5 54/19 1 338 36AH 4 7 2 1 19 1 485 D 5136 144HT Bittern/ACSS 1272 0 45/7 1 345 36AH 4 7 2 1 19 1 485 D 5136 144HT Diver/ACSS 1272 0 48/7 1 357 36AH 4 7 2 1 19 1 485 D 5136 147HT Pheasant/ACSS 1272 0 54/19 1 382 36AH 4 7 2 1 19 0 483 D 5136 147HT Dipper/ACSS 1351 5 45/7 1 386 36AH 4 7 2 1 19 0 483 D 5138 156HT Martin/ACSS 1351 5 54/19 1 424 38AH 5 5 2 5 20 5 521 D 5138 150HT Bobolink/ACSS 1431 0 45/7 1 427 38AH 5 6 2 5 19 6 498 D 5138 156HT Plover/ACSS 1431 0 54/19 1 465 38AH 5 5 2 5 20 5 521 D 5138 156HT Nuthatch/ACSS 1510 0 45/7 1 466 38AH 5 5 2 5 20 5 521 D 5140 162HT Parrot/ACSS 1510 0 54/19 1 505 40AH 6 4 2 9 21 3 541 E 5140 162HT Ratite/ACSS 1590 0 42/7 1 492 40AH 6 4 2 9 21 3 541 E 5140 162HT Lapwing/ACSS 1590 0 45/7 1 504 40AH 6 4 2 9 21 3 541 E 5140 162HT Falcon/ACSS 1590 0 54/19 1 544 40AH 6 4 2 9 21 3 541 E 5142 178HT Chukar/ACSS 1780 0 84/19 1 602 42AH 6 9 3 1 22 3 566 E 5142 178HT Mockingbird/ACSS 2034 5 72/7 1 681 42AH 6 9 3 1 22 3 566 E 5142 178HT Roadrunner/ACSS 2057 0 76/19 1 700 42AH 6 9 3 1 22 3 566 E 5144 184HT Bluebird/ACSS 2156 0 84/19 1 762 44AH 8 0 3 6 22 4 569 E 5144 181HT Kiwi/ACSS 2167 0 72/7 1 735 44AH 8 0 3 6 22 4 569 E 5144 188HT Thrasher/ACSS 2312 0 76/19 1 802 44AH 8 0 3 6 22 4 569 E 5148 197HT Joree/ACSS 2515 0 76/19 1 880 48AH 8 7 3 9 24 2 615 E HiTemp Terminal Connector for ACSS Conductor, 1 5º, 5 1 00HT Series (cont.) www.AFLglobal.com or 800-866-7385 © 2003, AFL, all rights reserved. PP-3-00747, Revision 6, 9.13.16 Specifications are subject to change without notice. 301 HiTemp ® ACSS ACCESSORIES Step 1: Catalog Number Determine the assembly catalog number based on the conductor being used Step 2: Extra High Voltage Finish For Extra High Voltage Finish, use "EHV" ( > 345 kV) For Standard Finish, leave blank (< 345 kV) Step 3: Assemble Catalog Number Example: For 795 Drake ACSS Conductor with an E pad and EHV finish, the complete catalog number is: 5830.116HTEEHV The 5800HT Series 90º Terminal Connector is specifically designed for ACSS conductors It is fabricated from a specially tempered aluminum that will transfer elevated current and dissipate increased heat more efficiently All HiTemp Terminal Connectors are designed for limited tension use, maintaining a minimum of 40% of the ASTM rated strength of the conductor Square edges of the compression accessory pad can cause Corona Pads with rounded edges and corners can be supplied by adding the catalog suffix ‘EHV’ Ordering Instructions HiTemp Terminal Connector for ACSS Conductor, 90º, 5800HT Series Catalog Number EHV Finish + Notes: 1 Pad Dimensions are on page 339 2 HiTemp AFL Filler Compound (AFCHT) Requirements are on page 340 3 Bolt Sizes and Torque Recommendations are on page 340 4 Installation Instructions for Terminals are on page 351 5 For more information on die selction and ordering instructions, see the Tools and Equipment section of this catalog Catalog Number Conductor Die Size Weight Total Length L Pad Size Code Name Size Stranding Diameter kcmil Al/St in lbs kg in mm 5876 688HT Partridge/ACSS 266 8 26/7 0 642 76AH 1 3 0 6 11 2 289 D 5820 781HT Woodcock/ACSS 336 4 22/7 0 701 20AH 1 3 0 6 10 8 274 D 5820 812HT Linnet/ACSS 336 4 26/7 0 720 20AH 1 3 0 6 10 8 274 D 5820 781HT Oriole/ACSS 336 4 30/7 0 741 20AH 1 3 0 6 10 8 274 D 5820 812HT Ptarmigan/ACSS 397 5 20/7 0 752 20AH 1 3 0 6 10 8 274 D 5820 812HT Brant/ACSS 397 5 24/7 0 772 20AH 1 3 0 6 10 8 274 D 5820 844HT Ibis/ACSS 397 5 26/7 0 783 20AH 1 2 0 5 10 7 272 D 5820 844HT Lark/ACSS 397 5 30/7 0 806 20AH 1 2 0 5 10 7 272 D 5820 875HT Tailorbird/ACSS 477 0 20/7 0 823 20AH 1 2 0 5 11 4 290 D 5824 938HT Flicker/ACSS 477 0 24/7 0 846 24AH 2 0 0 9 11 4 290 D 5824 938HT Hawk/ACSS 477 0 26/7 0 858 24AH 2 0 0 9 11 4 290 D 5824 938HT Hen/ACSS 477 0 30/7 0 883 24AH 2 0 0 9 11 4 290 D 5824 969HT Sapsucker/ACSS 556 5 22/7 0 901 24AH 2 0 0 9 11 4 290 D 5824 969HT Parakeet/ACSS 556 5 24/7 0 914 24AH 2 0 0 9 11 4 290 D 5827 100HT Dove/ACSS 556 5 26/7 0 927 27AH 2 4 1 1 12 8 325 D 5827 100HT Eagle/ACSS 556 5 30/7 0 953 27AH 2 4 1 1 12 8 325 D 5827 100HT Peacock/ACSS 605 0 24/7 0 953 27AH 2 4 1 1 12 8 325 D 5827 100HT Squab/ACSS 605 0 26/7 0 966 27AH 2 4 1 1 12 8 325 D 5827 106HT Wood Duck/ACSS 605 0 30/7 0 994 27AH 2 4 1 1 12 8 325 D 5827 106HT Teal/ACSS 605 0 30/19 0 994 27AH 2 4 1 1 12 8 325 D 5827 106HT Goldfinch/ACSS 636 0 22/7 0 963 27AH 2 4 1 1 12 8 325 D 5827 106HT Rook/ACSS 636 0 24/7 0 977 27AH 2 4 1 1 12 8 325 D 5827 106HT Grosbeak/ACSS 636 0 26/7 0 990 27AH 2 4 1 1 12 8 325 D www.AFLglobal.com or 800-866-7385 © 2003, AFL, all rights reserved. PP-3-00747, Revision 6, 9.13.16 Specifications are subject to change without notice. 302 HiTemp ® ACSS ACCESSORIES HiTemp Terminal Connector for ACSS Conductor, 90º, 5800HT Series (cont.) Catalog Number Conductor Die Size Weight Total Length L Pad Size Code Name Size Stranding Diameter kcmil Al/St in lbs kg in mm 5827 106HT Scoter/ACSS 636 0 30/7 1 019 27AH 2 4 1 1 12 8 325 D 5827 106HT Egret/ACSS 636 0 30/19 1 019 27AH 2 4 1 1 12 8 325 D 5827 106HT Flamingo/ACSS 666 6 24/7 1 000 27AH 2 4 1 1 12 8 325 D 5827 106HT Gannet/ACSS 666 6 26/7 1 014 27AH 2 4 1 1 12 8 325 D 5830 109HT Stilt/ACSS 715 5 24/7 1 036 30AH 3 3 1 5 14 2 361 D 5830 116HT Starling/ACSS 715 5 26/7 1 051 30AH 3 3 1 5 14 5 368 D 5830 116HT Redwing/ACSS 715 5 30/19 1 081 30AH 3 2 1 5 14 5 368 D 5830 116HT Cuckoo/ACSS 795 0 24/7 1 092 30AH 3 2 1 5 14 5 368 D 5830 122HT Drake/ACSS 795 0 26/7 1 108 30AH 3 2 1 5 14 5 368 D 5830 116HT Macaw/ACSS 795 0 42/7 1 055 30AH 3 2 1 5 14 5 368 D 5830 116HT Tern/ACSS 795 0 45/7 1 063 30AH 3 2 1 5 14 5 368 D 5830 116HT Condor/ACSS 795 0 54/7 1 092 30AH 3 2 1 5 14 5 368 D 5830 122HT Mallard/ACSS 795 0 30/19 1 140 30AH 3 0 1 4 14 7 373 D 5830 122HT Ruddy/ACSS 900 0 45/7 1 131 30AH 3 0 1 4 14 7 373 D 5830 122HT Canary/ACSS 900 0 54/7 1 162 30AH 3 0 1 4 14 7 373 D 5830 122HT Corncrake/ACSS 954 0 20/7 1 165 30AH 3 0 1 4 14 7 373 D 5830 125HT Redbird/ACSS 954 0 24/7 1 196 30AH 3 0 1 4 14 7 373 D 5830 122HT Rail/ACSS 954 0 45/7 1 165 30AH 3 0 1 4 14 7 373 D 5830 125HT Towhee/ACSS 954 0 48/7 1 175 30AH 3 0 1 4 14 7 373 D 5830 125HT Cardinal/ACSS 954 0 54/7 1 196 30AH 3 0 1 4 14 7 373 D 5834 134HT Canvasback/ACSS 954 0 30/19 1 248 34AH 4 3 2 0 15 5 394 D 5834 128HT Snowbird/ACSS 1033 5 42/7 1 203 34AH 4 4 2 0 15 5 394 D 5834 134HT Ortolan/ACSS 1033 5 45/7 1 212 34AH 4 3 2 0 15 5 394 D 5834 134HT Curlew/ACSS 1033 5 54/7 1 245 34AH 4 3 2 0 15 5 394 D 5834 134HT Bluejay/ACSS 1113 0 45/7 1 259 34AH 4 3 2 0 15 5 394 D 5834 138HT Finch/ACSS 1113 0 54/19 1 293 34AH 4 3 2 0 15 5 394 D 5834 138HT Bunting/ACSS 1192 5 45/7 1 302 34AH 4 2 1 9 15 5 394 D 5836 144HT Grackle/ACSS 1192 5 54/19 1 338 36AH 4 6 2 1 16 1 409 D 5836 144HT Bittern/ACSS 1272 0 45/7 1 345 36AH 4 6 2 1 16 1 409 D 5836 144HT Diver/ACSS 1272 0 48/7 1 357 36AH 4 6 2 1 16 1 409 D 5836 147HT Pheasant/ACSS 1272 0 54/19 1 382 36AH 4 6 2 1 16 1 409 D 5836 147HT Dipper/ACSS 1351 5 45/7 1 386 36AH 4 6 2 1 16 1 409 D 5838 156HT Martin/ACSS 1351 5 54/19 1 424 38AH 5 4 2 5 17 6 447 D 5838 150HT Bobolink/ACSS 1431 0 45/7 1 427 38AH 5 5 2 5 16 6 422 D 5838 156HT Plover/ACSS 1431 0 54/19 1 465 38AH 5 4 2 5 17 6 447 D 5838 156HT Nuthatch/ACSS 1510 0 45/7 1 466 38AH 5 4 2 5 17 6 447 D 5840 162HT Parrot/ACSS 1510 0 54/19 1 505 40AH 6 1 2 8 17 3 439 E 5840 162HT Ratite/ACSS 1590 0 42/7 1 492 40AH 6 1 2 8 17 3 439 E 5840 162HT Lapwing/ACSS 1590 0 45/7 1 504 40AH 6 1 2 8 17 3 439 E 5840 162HT Falcon/ACSS 1590 0 54/19 1 544 40AH 6 1 2 8 17 3 439 E 5842 178HT Chukar/ACSS 1780 0 84/19 1 602 42AH 7 0 3 2 18 5 470 E 5842 178HT Mockingbird/ACSS 2034 5 72/7 1 681 42AH 7 0 3 2 18 5 470 E 5842 178HT Roadrunner/ACSS 2057 0 76/19 1 700 42AH 7 0 3 2 18 5 470 E 5844 184HT Bluebird/ACSS 2156 0 84/19 1 762 44AH 8 3 3 8 18 7 475 E 5844 181HT Kiwi/ACSS 2167 0 72/7 1 735 44AH 8 3 3 8 18 7 475 E 5844 188HT Thrasher/ACSS 2312 0 76/19 1 802 44AH 8 3 3 8 18 7 475 E 5848 197HT Joree/ACSS 2515 0 76/19 1 880 48AH 10 6 4 8 20 3 516 E
