197 Quick Compress ® QuickCompress ® – AAC © 2003, AFL, all rights reserved. PP-3-00759, Revision 3, 3.9.2021 Specifications are subject to change without notice. AFLglobal.com | 800.866.7385 The Quick Compress Dead Ends are designed for fast and easy install-ation By using a high strength alloy, the compression length has been shortened for less compression bites while maintaining a minimum 95% of the ASTM rated strength The steel eye is pre-compressed and the dead end pre-filled, eliminat - ing installation steps The dead end tongue and terminal pad are each constructed with a 15º angle, which permits the terminal connector to be bolted in either the straight or the 30º position Both sides of the pad are finished, creating excellent electrical contact surfaces For pad to pad connections, AFL recommends the use of No 2 EJC The end tapers of all compression accessories are supplied with a high voltage finish for die sizes 12CD and above Corona bolts are furnished standard on 15º terminals for these section sizes The square edges of bolted pads of the compression accessories could cause Corona Pads with rounded edges and corners can be supplied by adding the catalog suffix 'EHV' Ordering Instructions Step 1: Assembly Catalog Number Determine the assembly catalog number based on the conductor being used Step 2: Terminal Connector For an assembly without a terminal connector, use 'NT' For an assembly with a terminal connector, leave blank Step 3: Extra High Voltage Finish For Extra High Voltage Finish, use 'EHV' ( ≥ 345 kV) For Standard Finish, leave blank ( < 345 kV) Step 4: Assemble Catalog Number. Example: For a vertical eye dead end with no terminal and EHV finish for 795 Arbutus, the complete catalog number is: VESE110NTEHV Assy Catalog Number Terminal Connector EHV Finish + + Notes: 1 Assembly Catalog Number includes dead end, terminal connector and aluminum hardware 2 Eye Dimensions are on page 257 3 Pad Dimensions are on page 257 4 Installation Instructions for Dead Ends are on page 266 5 Installation Instructions for Terminals are on page 272 6 For more information on die selection and ordering instructions, see Tools and Equipment tab in this catalog Quick Compress Dead Ends for AAC Conductor, Eye Type, Single Tongue, VESE/HESE Series HESE Style VESE Style © 2003, AFL, all rights reserved. PP-3-00759, Revision 3, 3.9.2021 Specifications are subject to change without notice. AFLglobal.com | 800.866.7385 198 Quick Compress ® QuickCompress ® – AAC ASSEMBLY CATALOG NUMBER CONDUCTOR DIE SIZE TOTAL WEIGHT DIMENSION L PAD SIZE VERTICAL EYE HORIZONTAL EYE CODE WORD SIZE STRANDING DIAMETER KCMIL IN LBS KG IN MM VESE070 HESE070 Peony 300 6 19 0 629 07CD 1 6 0 73 8 9 226 B VESE070 HESE070 Tulip 336 4 19 0 666 07CD 1 6 0 73 8 9 226 B VESE070 HESE070 Daffodil 350 0 19 0 679 07CD 1 6 0 73 8 9 226 B VESE080 HESE080 Canna 397 5 19 0 724 08CD 2 0 0 91 9 3 236 B VESE090 HESE090 Goldentuft 450 0 19 0 770 09CD 2 8 1 27 10 4 265 B VESE090 HESE090 Cosmos 477 0 19 0 793 09CD 2 8 1 27 10 4 265 B VESE090 HESE090 Zinnia 500 0 19 0 811 09CD 2 8 1 27 10 4 265 B VESE100 HESE100 Dahlia 556 5 19 0 856 10CD 3 2 1 45 10 9 278 B VESE100 HESE100 Meadowsweet 600 0 37 0 891 10CD 3 2 1 45 10 9 278 B VESE100 HESE100 Orchid 636 0 37 0 918 10CD 3 2 1 45 10 9 278 B VESE100 HESE100 Heuchera 650 0 37 0 928 10CD 3 2 1 45 10 9 278 B VESE110 HESE110 Verbena 700 0 37 0 963 11CD 5 1 2 31 11 8 298 D VESE110 HESE110 Violet 715 5 37 0 974 11CD 5 1 2 31 11 8 298 D VESE110 HESE110 Petunia 750 0 37 0 997 11CD 5 1 2 31 11 8 298 D VESE110 HESE110 Arbutus 795 0 37 1 026 11CD 5 1 2 31 11 8 298 D VESE110 HESE110 — 800 0 61 1 031 11CD 5 1 2 31 11 8 298 D VESE120 HESE120 Cockscomb 900 0 37 1 092 12CD 5 6 2 54 12 2 310 D VESE120 HESE120 Magnolia 954 0 37 1 124 12CD 5 6 2 54 12 2 310 D VESE130 HESE130 Hawkweed 1000 0 37 1 151 13CD 7 5 3 40 14 1 359 D VESE130 HESE130 Bluebell 1033 5 37 1 170 13CD 7 5 3 40 14 1 359 D VESE130 HESE130 Marigold 1113 0 61 1 216 13CD 7 5 3 40 14 1 359 D VESE140 HESE140 Hawthorn 1192 5 61 1 258 14CD 8 4 3 81 14 6 370 D VESE140 HESE140 — 1250 0 91 1 289 14CD 8 4 3 81 14 6 370 D VESE140 HESE140 Narcissus 1272 0 61 1 300 14CD 8 4 3 81 14 6 370 D VESE140 HESE140 — 1300 0 91 1 315 14CD 8 4 3 81 14 6 370 D VESE150 HESE150 Columbine 1351 5 61 1 340 15CD 9 3 4 22 15 0 381 D VESE150 HESE150 Carnation 1431 0 61 1 379 15CD 9 3 4 22 15 0 381 D VESE150 HESE150 — 1500 0 91 1 412 15CD 9 3 4 22 15 0 381 D VESE150 HESE150 Gladiolus 1510 5 61 1 417 15CD 9 3 4 22 15 0 381 D VESE160 HESE160 Coreopsis 1590 0 61 1 454 16CD 11 8 5 35 16 3 414 D VESE170 HESE170 Jessamine 1750 0 61 1 525 17CD 14 5 6 58 16 7 424 E VESE180 HESE180 Cowslip 2000 0 91 1 630 18CD 15 7 7 12 17 1 435 E VESE190 HESE190 Sagebrush 2250 0 91 1 729 19CD 20 0 9 07 19 1 484 E VESE190 HESE190 — 2300 0 1 750 19CD 20 0 9 07 19 1 484 E VESE200 HESE200 Lupine 2500 0 91 1 823 20CD 21 3 9 66 19 5 495 E Quick Compress Dead Ends for AAC Conductor, Eye Type, Single Tongue, VESE/HESE Series (cont.) 199 Quick Compress ® QuickCompress ® – AAC © 2003, AFL, all rights reserved. PP-3-00759, Revision 3, 3.9.2021 Specifications are subject to change without notice. AFLglobal.com | 800.866.7385 The Quick Compress Dead Ends are designed for fast and easy installation By using a high strength alloy, the compression length has been shortened for less compression bites while maintaining a minimum 95% of the ASTM rated strength The steel eye is pre-compressed and the dead end pre-filled, eliminat - ing installation steps The dead end tongue and terminal pad are each constructed with a 15º angle, which permits the terminal connector to be bolted in either the straight or the 30º position Both sides of the pad are finished, creating excellent electrical contact surfaces For pad to pad connections, AFL recommends the use of No 2 EJC The end tapers of all compression accessories are supplied with a high voltage finish for die sizes 12CD and above Corona bolts are furnished standard on 15º terminals for these section sizes The square edges of bolted pads of the compression accessories could cause Corona Pads with rounded edges and corners can be supplied by adding the catalog suffix 'EHV' Ordering Instructions Step 1: Assembly Catalog Number Determine the assembly catalog number based on the conductor being used Step 2: Terminal Connector For an assembly without a terminal connector, use 'NT' For an assembly with a terminal connector, leave blank Step 3: Extra High Voltage Finish For Extra High Voltage Finish, use 'EHV' ( ≥ 345 kV) For Standard Finish, leave blank ( < 345 kV) Step 4: Assemble Catalog Number. Example: For a vertical eye dead end with no terminal and EHV finish for 795 Arbutus, the complete catalog number is: VEDE110NTEHV Assy Catalog Number Terminal Connector EHV Finish + + Notes: 1 Assembly Catalog Number includes dead end, two terminal connectors and aluminum hardware 2 Eye Dimensions are on page 257 3 Pad Dimensions are on page 257 4 Installation Instructions for Dead Ends are on page 266 5 Installation Instructions for Terminals are on page 272 6 For more information on die selection and ordering instructions, see Tools and Equipment tab in this catalog Quick Compress Dead Ends for AAC Conductor, Eye Type, Double Tongue, VEDE/HEDE Series HEDE Style VEDE Style © 2003, AFL, all rights reserved. PP-3-00759, Revision 3, 3.9.2021 Specifications are subject to change without notice. AFLglobal.com | 800.866.7385 200 Quick Compress ® QuickCompress ® – AAC Quick Compress Dead Ends for AAC Conductor, Eye Type, Double Tongue, VEDE/HEDE Series (cont.) ASSEMBLY CATALOG NUMBER CONDUCTOR DIE SIZE TOTAL WEIGHT DIMENSION L PAD SIZE CODE WORD SIZE STRANDING DIAMETER VERTICAL EYE HORIZONTAL EYE KCMIL AL IN LBS KG IN MM VEDE070 HEDE070 Peony 300 0 19 0 629 07CD 2 5 1 13 8 9 226 B VEDE070 HEDE070 Tulip 336 4 19 0 666 07CD 2 5 1 13 8 9 226 B VEDE070 HEDE070 Daffodil 350 0 19 0 679 07CD 2 5 1 13 8 9 226 B VEDE080 HEDE080 Canna 397 5 19 0 724 08CD 3 0 1 36 9 3 236 B VEDE090 HEDE090 Goldentuft 450 0 19 0 770 09CD 4 1 1 86 10 4 265 B VEDE090 HEDE090 Cosmos 477 0 19 0 793 09CD 4 1 1 86 10 4 265 B VEDE090 HEDE090 Zinnia 500 0 19 0 811 09CD 4 1 1 86 10 4 265 B VEDE100 HEDE100 Dahlia 556 5 19 0 856 10CD 4 8 2 18 10 9 278 B VEDE100 HEDE100 Meadowsweet 600 0 37 0 891 10CD 4 8 2 18 10 9 278 B VEDE100 HEDE100 Orchid 636 0 37 0 918 10CD 4 8 2 18 10 9 278 B VEDE100 HEDE100 Heuchera 650 0 37 0 928 10CD 4 8 2 18 10 9 278 B VEDE110 HEDE110 Verbena 700 0 37 0 963 11CD 7 3 3 31 11 8 298 D VEDE110 HEDE110 Violet 715 5 37 0 974 11CD 7 3 3 31 11 8 298 D VEDE110 HEDE110 Petunia 750 0 37 0 997 11CD 7 3 3 31 11 8 298 D VEDE110 HEDE110 Arbutus 795 0 37 1 026 11CD 7 3 3 31 11 8 298 D VEDE110 HEDE110 — 800 0 61 1 031 11CD 7 3 3 31 11 8 298 D VEDE120 HEDE120 Cockscomb 900 0 37 1 092 12CD 8 3 3 76 12 2 310 D VEDE120 HEDE120 Magnolia 954 0 37 1 124 12CD 8 3 3 76 12 2 310 D VEDE130 HEDE130 Hawkweed 1000 0 37 1 151 13CD 10 6 4 80 14 1 359 D VEDE130 HEDE130 Bluebell 1033 5 37 1 170 13CD 10 6 4 80 14 1 359 D VEDE130 HEDE130 Marigold 1113 0 61 1 216 13CD 10 6 4 80 14 1 359 D VEDE140 HEDE140 Hawthorn 1192 5 61 1 258 14CD 12 0 5 44 14 6 370 D VEDE140 HEDE140 — 1250 0 91 1 289 14CD 12 0 5 44 14 6 370 D VEDE140 HEDE140 Narcissus 1272 0 61 1 300 14CD 12 0 5 44 14 6 370 D VEDE140 HEDE140 — 1300 0 91 1 315 14CD 12 0 5 44 14 6 370 D VEDE150 HEDE150 Columbine 1351 5 61 1 340 15CD 13 3 6 03 15 0 381 D VEDE150 HEDE150 Carnation 1431 0 61 1 379 15CD 13 3 6 03 15 0 381 D VEDE150 HEDE150 — 1500 0 91 1 412 15CD 13 3 6 03 15 0 381 D VEDE150 HEDE150 Gladiolus 1510 5 61 1 417 15CD 13 3 6 03 15 0 381 D VEDE160 HEDE160 Coreopsis 1590 0 61 1 454 16CD 16 4 7 44 16 3 414 D VEDE170 HEDE170 Jessamine 1750 0 61 1 525 17CD 20 2 9 16 16 7 424 E VEDE180 HEDE180 Cowslip 2000 0 91 1 630 18CD 22 0 9 98 17 1 435 E VEDE190 HEDE190 Sagebrush 2250 0 91 1 729 19CD 27 4 12 43 19 1 484 E VEDE190 HEDE190 — 2300 0 91 1 750 19CD 27 4 12 43 19 1 484 E VEDE200 HEDE200 Lupine 2500 0 91 1 823 20CD 29 2 13 24 19 5 495 E 201 Quick Compress ® QuickCompress ® – AAC © 2003, AFL, all rights reserved. PP-3-00759, Revision 3, 3.9.2021 Specifications are subject to change without notice. AFLglobal.com | 800.866.7385 The Quick Compress Dead Ends are designed for fast and easy installation By using a high strength alloy, the compression length has been shortened for less compression bites while maintaining a minimum 95% of the ASTM rated strength The adjustable steel clevis is pre-compressed and the dead end pre- filled, eliminating installation steps The dead end tongue and terminal pad are each constructed with a 15º angle, which permits the terminal connector to be bolted in either the straight or the 30º position Both sides of the pad are finished, creating excellent electrical contact surfaces For pad to pad connections, AFL recommends the use of No 2 EJC The end tapers of all compression accessories are supplied with a high voltage finish for die sizes 12CD and above Corona bolts are furnished standard on 15º terminals for these section sizes The square edges of bolted pads of the compression accessories could cause Corona Pads with rounded edges and corners can be supplied by adding the catalog suffix 'EHV' Ordering Instructions Step 1: Assembly Catalog Number Determine the assembly catalog number based on the conductor being used Step 2: Terminal Connector For an assembly without a terminal connector, use 'NT' For an assembly with a terminal connector, leave blank Step 3: Extra High Voltage Finish For Extra High Voltage Finish, use 'EHV' ( ≥ 345 kV) For Standard Finish, leave blank ( < 345 kV) Step 4: Assemble Catalog Number. Example: For an adjustable clevis dead end with no terminal and EHV finish for 795 Arbutus, the complete catalog number is: ACSE110NTEHV Assy Catalog Number Terminal Connector EHV Finish + + Notes: 1 Assembly Catalog Number includes dead end, terminal connector and aluminum hardware 2 Clevis Dimensions are on page 258 3 Pad Dimensions are on page 257 4 Installation Instructions for Dead Ends are on page 266 5 Installation Instructions for Terminals are on page 272 6 For more information on die selection and ordering instructions, see Tools and Equipment tab in this catalog Quick Compress Dead Ends for AAC Conductor, Adjustable Clevis Type, Single Tongue, ACSE Series © 2003, AFL, all rights reserved. PP-3-00759, Revision 3, 3.9.2021 Specifications are subject to change without notice. AFLglobal.com | 800.866.7385 202 Quick Compress ® QuickCompress ® – AAC Quick Compress Dead Ends for AAC Conductor, Adjustable Clevis Type, Single Tongue, ACSE Series (cont.) ASSEMBLY CATALOG NUMBER CONDUCTOR DIE SIZE TOTAL WEIGHT DIMENSION L PAD SIZE CODE WORD SIZE STRANDING DIAMETER KCMIL IN LBS KG IN MM ACSE070 Peony 300 0 19 0 629 07CD 4 1 1 86 16 6 442 B ACSE070 Tulip 336 4 19 0 666 07CD 4 1 1 86 16 6 442 B ACSE070 Daffodil 350 0 19 0 679 07CD 4 1 1 86 16 6 442 B ACSE080 Canna 397 5 19 0 724 08CD 4 8 2 18 17 2 437 B ACSE090 Goldentuft 450 0 19 0 770 09CD 5 8 2 63 18 3 465 B ACSE090 Cosmos 477 0 19 0 793 09CD 5 8 2 63 18 3 465 B ACSE090 Zinnia 500 0 19 0 811 09CD 5 8 2 63 18 3 465 B ACSE100 Dahlia 556 5 19 0 856 10CD 6 2 2 81 18 8 476 B ACSE100 Meadowsweet 600 0 37 0 891 10CD 6 2 2 81 18 8 476 B ACSE100 Orchid 636 0 37 0 918 10CD 6 2 2 81 18 8 476 B ACSE100 Heuchera 650 0 37 0 928 10CD 6 2 2 81 18 8 476 B ACSE110 Verbena 700 0 37 0 963 11CD 10 7 4 85 21 8 554 D ACSE110 Violet 715 5 37 0 974 11CD 10 7 4 85 21 8 554 D ACSE110 Petunia 750 0 37 0 997 11CD 10 7 4 85 21 8 554 D ACSE110 Arbutus 795 0 37 1 026 11CD 10 7 4 85 21 8 554 D ACSE110 — 800 0 61 1 031 11CD 10 7 4 85 21 8 554 D ACSE120 Cockscomb 900 0 37 1 092 12CD 11 2 5 08 22 3 565 D ACSE120 Magnolia 954 0 37 1 124 12CD 11 2 5 08 22 3 565 D ACSE130 Hawkweed 1000 0 37 1 151 13CD 13 9 6 30 23 8 605 D ACSE130 Bluebell 1033 5 37 1 170 13CD 13 9 6 30 23 8 605 D ACSE130 Marigold 1113 0 61 1 216 13CD 13 9 6 30 23 8 605 D ACSE140 Hawthorn 1192 5 61 1 258 14CD 14 8 6 71 24 3 616 D ACSE140 — 1250 0 91 1 289 14CD 14 8 6 71 24 3 616 D ACSE140 Narcissus 1272 0 61 1 300 14CD 14 8 6 71 24 3 616 D ACSE140 — 1300 0 91 1 315 14CD 14 8 6 71 24 3 616 D ACSE150 Columbine 1351 5 61 1 340 15CD 15 7 7 12 24 7 627 D ACSE150 Carnation 1431 0 61 1 379 15CD 15 7 7 12 24 7 627 D ACSE150 — 1500 0 91 1 412 15CD 15 7 7 12 24 7 627 D ACSE150 Gladiolus 1510 5 61 1 417 15CD 15 7 7 12 24 7 627 D ACSE160 Coreopsis 1590 0 61 1 454 16CD 21 9 9 93 28 4 721 D ACSE170 Jessamine 1750 0 61 1 525 17CD 24 6 11 16 28 9 734 E ACSE180 Cowslip 2000 0 91 1 630 18CD 25 8 11 70 29 3 743 E ACSE190 Sagebrush 2250 0 91 1 729 19CD 33 9 15 38 31 1 789 E ACSE190 — 2300 0 91 1 750 19CD 33 9 15 38 31 1 789 E ACSE200 Lupine 2500 0 91 1 823 20CD 35 2 15 97 31 5 800 E 203 Quick Compress ® QuickCompress ® – AAC © 2003, AFL, all rights reserved. PP-3-00759, Revision 3, 3.9.2021 Specifications are subject to change without notice. AFLglobal.com | 800.866.7385 The Quick Compress Dead Ends are designed for fast and easy installation By using a high strength alloy, the compression length has been shortened for less compression bites while maintaining a minimum 95% of the ASTM rated strength The adjustable steel eye is pre-compressed and the dead end pre- filled, eliminating installation steps The dead end tongue and terminal pad are each constructed with a 15º angle, which permits the terminal connector to be bolted in either the straight or the 30º position Both sides of the pad are finished, creating excellent electrical contact surfaces For pad to pad connections, AFL recommends the use of No 2 EJC The end tapers of all compression accessories are supplied with a high voltage finish for die sizes 12CD and above Corona bolts are furnished standard on 15º terminals for these section sizes The square edges of bolted pads of the compression accessories could cause Corona Pads with rounded edges and corners can be supplied by adding the catalog suffix 'EHV' Ordering Instructions Step 1: Assembly Catalog Number Determine the assembly catalog number based on the conductor being used Step 2: Terminal Connector For an assembly without a terminal connector, use 'NT' For an assembly with a terminal connector, leave blank Step 3: Extra High Voltage Finish For Extra High Voltage Finish, use 'EHV' ( ≥ 345 kV) For Standard Finish, leave blank ( < 345 kV) Step 4: Assemble Catalog Number. Example: For an adjustable eye dead end with no terminal and EHV finish for 795 Arbutus, the complete catalog number is: AESE110NTEHV Assy Catalog Number Terminal Connector EHV Finish + + Notes: 1 Assembly Catalog Number includes dead end, terminal connector and aluminum hardware 2 Eye Dimensions are on page 258 3 Pad Dimensions are on page 257 4 Installation Instructions for Dead Ends are on page 266 5 Installation Instructions for Terminals are on page 272 6 For more information on die selection and ordering instructions, see Tools and Equipment tab in this catalog Quick Compress Dead Ends for AAC Conductor, Adjustable Eye Type, Single Tongue, AESE Series © 2003, AFL, all rights reserved. PP-3-00759, Revision 3, 3.9.2021 Specifications are subject to change without notice. AFLglobal.com | 800.866.7385 204 Quick Compress ® QuickCompress ® – AAC Quick Compress Dead Ends for AAC Conductor, Adjustable Eye Type, Single Tongue, AESE Series (cont.) ASSEMBLY CATALOG NUMBER CONDUCTOR DIE SIZE TOTAL WEIGHT DIMENSION L PAD SIZE CODE WORD SIZE STRANDING DIAMETER KCMIL IN LBS KG IN MM AESE070 Peony 300 6 19 0 629 07CD 2 6 1 18 13 8 351 B AESE070 Tulip 336 4 19 0 666 07CD 2 6 1 18 13 8 351 B AESE070 Daffodil 350 0 19 0 679 07CD 2 6 1 18 13 8 351 B AESE080 Canna 397 5 19 0 724 08CD 3 7 1 68 14 8 377 B AESE090 Goldentuft 450 0 19 0 770 09CD 5 3 2 40 16 4 415 B AESE090 Cosmos 477 0 19 0 793 09CD 5 3 2 40 16 4 415 B AESE090 Zinnia 500 0 19 0 811 09CD 5 3 2 40 16 4 415 B AESE100 Dahlia 556 5 19 0 856 10CD 5 7 2 59 16 8 427 B AESE100 Meadowsweet 600 0 37 0 891 10CD 5 7 2 59 16 8 427 B AESE100 Orchid 636 0 37 0 918 10CD 5 7 2 59 16 8 427 B AESE100 Heuchera 650 0 37 0 928 10CD 5 7 2 59 16 8 427 B AESE110 Verbena 700 0 37 0 963 11CD 8 7 3 95 19 1 485 D AESE110 Violet 715 5 37 0 974 11CD 8 7 3 95 19 1 485 D AESE110 Petunia 750 0 37 0 997 11CD 8 7 3 95 19 1 485 D AESE110 Arbutus 795 0 37 1 026 11CD 8 7 3 95 19 1 485 D AESE110 — 800 0 61 1 031 11CD 8 7 3 95 19 1 485 D AESE120 Cockscomb 900 0 37 1 092 12CD 9 3 4 22 19 6 497 D AESE120 Magnolia 954 0 37 1 124 12CD 9 3 4 22 19 6 497 D AESE130 Hawkweed 1000 0 37 1 151 13CD 13 1 5 94 21 6 549 D AESE130 Bluebell 1033 5 37 1 170 13CD 13 1 5 94 21 6 549 D AESE130 Marigold 1113 0 61 1 216 13CD 13 1 5 94 21 6 549 D AESE140 Hawthorn 1192 5 61 1 258 14CD 14 0 6 35 22 1 561 D AESE140 — 1250 0 91 1 289 14CD 14 0 6 35 22 1 561 D AESE140 Narcissus 1272 0 61 1 300 14CD 14 0 6 35 22 1 561 D AESE140 — 1300 0 91 1 315 14CD 14 0 6 35 22 1 561 D AESE150 Columbine 1351 5 61 1 340 15CD 14 9 6 76 22 5 571 D AESE150 Carnation 1431 0 61 1 379 15CD 14 9 6 76 22 5 571 D AESE150 — 1500 0 91 1 412 15CD 14 9 6 76 22 5 571 D AESE150 Gladiolus 1510 5 61 1 417 15CD 14 9 6 76 22 5 571 D AESE160 Coreopsis 1590 0 61 1 454 16CD 21 8 9 89 25 7 653 D AESE170 Jessamine 1750 0 61 1 525 17CD 24 6 11 16 26 2 664 E AESE180 Cowslip 2000 0 91 1 630 18CD 25 8 11 70 26 5 674 E AESE190 Sagebrush 2250 0 91 1 729 19CD 31 0 14 60 28 1 713 E AESE190 — 2300 0 91 1 750 19CD 31 0 14 60 28 1 713 E AESE200 Lupine 2500 0 91 1 823 20CD 32 3 14 65 28 5 724 E 205 Quick Compress ® QuickCompress ® – AAC © 2003, AFL, all rights reserved. PP-3-00759, Revision 3, 3.9.2021 Specifications are subject to change without notice. AFLglobal.com | 800.866.7385 The Quick Compress CJE Series Joints are designed for fast and easy installation By using a high strength alloy, the compres - sion length has been shortened for less compression bites while maintaining a minimum 95% of the ASTM rated strength The compression joint is pre-filled, eliminating an installation step Each compression joint has a center stop to ensure proper inser - tion of the conductor The end tapers of all compression accessories are supplied with a high voltage finish for die size sections 12CD and above Ordering Instructions Step 1: Assembly Catalog Number Determine the assembly catalog number based on the conductor being used Example: A compression joint for 795 Arbutus conductor, the complete catalog number is: CJE11 Notes: 1 Installation Instructions for Compression Joints are on page 268 2 For more information on die selection and ordering instructions, see Tools and Equipment tab in this catalog Quick Compress Compression Joints for AAC Conductor, CJE Series CATALOG NUMBER CONDUCTOR DIE SIZE TOTAL WEIGHT DIMENSION L CODE NAME SIZE STRANDING DIAMETER KCMIL IN LBS KG IN MM CJE07 Peony 300 0 19 0 629 07CD 0 3 0 13 5 6 142 CJE07 Tulip 336 4 19 0 666 07CD 0 3 0 13 5 6 142 CJE07 Daffodil 350 0 19 0 679 07CD 0 3 0 13 5 6 142 CJE08 Canna 397 5 19 0 724 08CD 0 4 0 20 6 4 163 CJE09 Goldentuft 450 0 19 0 770 09CD 0 6 0 28 7 2 183 CJE09 Cosmos 477 0 19 0 793 09CD 0 6 0 28 7 2 183 CJE09 Zinnia 500 0 19 0 811 09CD 0 6 0 28 7 2 183 CJE10 Dahlia 556 5 19 0 856 10CD 0 9 0 39 8 0 203 CJE10 Meadowsweet 600 0 37 0 891 10CD 0 9 0 39 8 0 203 CJE10 Orchid 636 0 37 0 918 10CD 0 9 0 39 8 0 203 CJE10 Heuchera 650 0 37 0 928 10CD 0 9 0 39 8 0 203 CJE11 Verbena 700 0 37 0 963 11CD 1 1 0 50 8 8 224 CJE11 Violet 715 5 37 0 974 11CD 1 1 0 50 8 8 224 CJE11 Petunia 750 0 37 0 997 11CD 1 1 0 50 8 8 224 CJE11 Arbutus 795 0 37 1 026 11CD 1 1 0 50 8 8 224 CJE11 — 800 0 61 1 031 11CD 1 1 0 50 8 8 224 CJE12 Cockscomb 900 0 37 1 092 12CD 1 5 0 68 9 6 244 CJE12 Magnolia 964 0 37 1 124 12CD 1 5 0 68 9 6 244 © 2003, AFL, all rights reserved. PP-3-00759, Revision 3, 3.9.2021 Specifications are subject to change without notice. AFLglobal.com | 800.866.7385 206 Quick Compress ® QuickCompress ® – AAC CATALOG NUMBER CONDUCTOR DIE SIZE TOTAL WEIGHT DIMENSION L CODE NAME SIZE STRANDING DIAMETER KCMIL IN LBS KG IN MM CJE12 Magnolia 954 0 37 1 124 12CD 1 5 0 68 9 6 244 CJE13 Hawkweed 1000 0 37 1 151 13CD 1 8 0 82 10 4 264 CJE13 Bluebell 1033 5 37 1 170 13CD 1 8 0 82 10 4 264 CJE13 Marigold 1113 0 61 1 216 13CD 1 8 0 82 10 4 264 CJE14 Hawthorn 1192 5 61 1 258 14CD 2 3 1 04 11 2 284 CJE14 — 1250 0 91 1 289 14CD 2 3 1 04 11 2 284 CJE14 Narcissus 1272 0 61 1 300 14CD 2 3 1 04 11 2 284 CJE14 — 1300 0 91 1 315 14CD 2 3 1 04 11 2 284 CJE15 Columbine 1351 5 61 1 340 15CD 2 8 1 27 12 0 305 CJE15 Carnation 1431 0 61 1 379 15CD 2 8 1 27 12 0 305 CJE15 — 1500 0 91 1 412 15CD 2 8 1 27 12 0 305 CJE15 Gladiolus 1510 5 61 1 417 15CD 2 8 1 27 12 0 305 CJE16 Coreopsis 1590 0 61 1 454 16CD 3 4 1 54 12 8 325 CJE17 Jessamine 1750 0 61 1 525 17CD 4 1 1 86 13 6 345 CJE18 Cowslip 2000 0 91 1 630 18CD 4 9 2 22 14 4 366 CJE19 Sagebrush 2250 0 91 1 729 19CD 5 7 2 59 15 2 386 CJE19 — 2300 0 91 1 750 19CD 5 7 2 59 15 2 386 CJE20 Lupine 2500 0 91 1 823 20CD 6 7 3 04 16 0 406 Quick Compress Compression Joints for AAC Conductor, CJE Series (cont.) 207 Quick Compress ® QuickCompress ® – AAC © 2003, AFL, all rights reserved. PP-3-00759, Revision 3, 3.9.2021 Specifications are subject to change without notice. AFLglobal.com | 800.866.7385 The Quick Compress Replacement Joints are used to replace damaged conductor in midspan They are designed for fast and easy installation By using a high strength alloy, the compres - sion length has been shortened for less compression bites, while maintaining a minimum 95% of the ASTM rated strength The replacement joint is pre-filled, eliminating an installation step The end tapers of all compression accessories are supplied with a high voltage finish for die size sections 12CD and above Ordering Instructions Step 1: Assembly Catalog Number Determine the assembly catalog number based on the conductor being used Step 2: Determine Length of Conductor Removed (XX) Determine the length of conductor (XX) that will be cut out, to the nearest inch (Maximum 48") Step 3: Assemble Catalog Number Example: A replacement compression joint for 795 Arbutus conductor with a removed conductor length of 24 inches, the complete catalog number is: CJE110R24 Notes: 1 Installation Instructions for Compression Joints are on page 268 2 For more information on die selection and ordering instructions, see Tools and Equipment tab in this catalog Quick Compress Replacement Compression Joints for AAC Conductor, CJER Series Catalog Number Removed Conductor Length (XX) + CATALOG NUMBER CONDUCTOR DIE SIZE DIMENSION G CODE WORD SIZE STRANDING DIAMETER KCMIL AL IN IN MM CJE070RXX Peony 300 6 19 0 629 07CD 7 6 192 CJE070RXX Tulip 336 4 19 0 666 07CD 7 6 192 CJE070RXX Daffodil 350 0 19 0 679 07CD 7 6 192 CJE080RXX Canna 397 5 19 0 724 08CD 8 4 212 CJE090RXX Goldentuft 450 0 19 0 770 09CD 9 2 233 CJE090RXX Cosmos 477 0 19 0 793 09CD 9 2 233 CJE090RXX Zinnia 500 0 19 0 811 09CD 9 2 233 CJE100RXX Dahlia 556 5 19 0 856 10CD 10 0 253 CJE100RXX Meadowsweet 600 0 37 0 891 10CD 10 0 253 CJE100RXX Orchid 636 0 37 0 918 10CD 10 0 253 CJE100RXX Heuchera 650 0 37 0 928 10CD 10 0 253 CJE110RXX Verbena 700 0 37 0 963 11CD 10 8 273 CJE110RXX Violet 715 5 37 0 974 11CD 10 8 273 CJE110RXX Petunia 750 0 37 0 997 11CD 10 8 273 CJE110RXX Arbutus 795 0 37 1 026 11CD 10 8 273 CJE110RXX — 800 0 61 1 031 11CD 10 8 273 CJE120RXX Cockscomb 900 0 37 1 092 12CD 11 6 294 © 2003, AFL, all rights reserved. PP-3-00759, Revision 3, 3.9.2021 Specifications are subject to change without notice. AFLglobal.com | 800.866.7385 208 Quick Compress ® QuickCompress ® – AAC CATALOG NUMBER CONDUCTOR DIE SIZE DIMENSION G CODE WORD SIZE STRANDING DIAMETER KCMIL AL IN IN MM CJE120RXX Magnolia 954 0 37 1 124 12CD 11 8 294 CJE130RXX Hawkweed 1000 0 37 1 151 13CD 12 4 314 CJE130RXX Bluebell 1033 5 37 1 170 13CD 12 4 314 CJE130RXX Marigold 1113 0 61 1 216 13CD 12 4 314 CJE140RXX Hawthorn 1192 5 61 1 258 14CD 13 2 334 CJE140RXX — 1250 0 91 1 289 14CD 13 2 334 CJE140RXX Narcissus 1272 0 61 1 300 14CD 13 2 334 CJE140RXX — 1300 0 91 1 315 14CD 13 2 334 CJE150RXX Columbine 1351 5 61 1 340 15CD 14 0 355 CJE150RXX Carnation 1431 0 61 1 379 15CD 14 0 355 CJE150RXX — 1500 0 91 1 412 15CD 14 0 355 CJE150RXX Gladiolus 1510 5 61 1 417 15CD 14 0 355 CJE160RXX Coreopsis 1590 0 61 1 454 16CD 14 8 375 CJE170RXX Jessamine 1750 0 61 1 525 17CD 15 6 395 CJE180RXX Cowslip 2000 0 91 1 630 18CD 16 4 416 CJE190RXX Sagebrush 2250 0 91 1 729 19CD 17 2 436 CJE190RXX — 2300 0 — 1 750 19CD 17 2 436 CJE200RXX Lupine 2500 0 91 1 823 20CD 18 0 456 Quick Compress Replacement Compression Joints for AAC Conductor, CJER Series (cont.) 209 Quick Compress ® QuickCompress ® – AAC © 2003, AFL, all rights reserved. PP-3-00759, Revision 3, 3.9.2021 Specifications are subject to change without notice. AFLglobal.com | 800.866.7385 The Quick Compress Repair Sleeve is designed for ACSR, AAC, AAAC and ACAR conductors The repair sleeve incorporates an improved design of interlocking extrusions, providing a permanent grip on the conductor when compressed The repair sleeve will restore the conductor to 95% of its ASTM rated strength where up to one-third of the aluminum strands are damaged Ordering Instructions Step 1: Assembly Catalog Number Determine the assembly catalog number based on the conductor being used Example: A repair sleeve for 795 Arbutus conductor, the complete catalog number is: RS11 Notes: 1 Installation Instructions for Compression Joints are on page 270 2 For more information on die selection and ordering instructions, see the AFL Tool Catalog Quick Compress Repair Sleeve for AAC Conductor, RS Series AFL NO. CONDUCTOR DIE SIZE TOTAL WEIGHT DIMENSION L CODE WORD SIZE STRANDING DIAMETER KCMIL IN LBS KG IN MM RS07 Peony 300 0 19 0 629 07CD 0 4 0 17 8 4 213 RS07 Tulip 336 4 19 0 666 07CD 0 4 0 17 8 4 213 RS07 Daffodil 350 0 19 0 679 07CD 0 4 0 17 8 4 213 RS08 Canna 397 5 19 0 724 08CD 0 6 0 26 9 6 244 RS09 Goldentuft 450 0 19 0 770 09CD 0 8 0 38 10 8 274 RS09 Cosmos 477 0 19 0 793 09CD 0 8 0 38 10 8 274 RS09 Zinnia 500 0 19 0 811 09CD 0 8 0 38 10 8 274 RS10 Dahlia 556 5 19 0 856 10CD 1 1 0 50 12 0 305 RS10 Meadowsweet 600 0 37 0 891 10CD 1 1 0 50 12 0 305 RS10 Orchid 636 0 37 0 918 10CD 1 1 0 50 12 0 305 RS10 Heuchera 650 0 37 0 928 10CD 1 1 0 50 12 0 305 RS11 Verbena 700 0 37 0 963 11CD 1 5 0 68 13 2 335 RS11 Violet 715 5 37 0 974 11CD 1 5 0 68 13 2 335 RS11 Petunia 750 0 37 0 997 11CD 1 5 0 68 13 2 335 RS11 Arbutus 795 0 37 1 026 11CD 1 5 0 68 13 2 335 RS11 — 800 0 61 1 031 11CD 1 5 0 68 13 2 335 RS12 Cockscomb 900 0 37 1 092 12CD 1 9 0 86 14 4 366 RS12 Magnolia 954 0 37 1 124 12CD 1 9 0 86 14 4 366 © 2003, AFL, all rights reserved. PP-3-00759, Revision 3, 3.9.2021 Specifications are subject to change without notice. AFLglobal.com | 800.866.7385 210 Quick Compress ® QuickCompress ® – AAC AFL NO. CONDUCTOR DIE SIZE TOTAL WEIGHT DIMENSION L CODE WORD SIZE STRANDING DIAMETER KCMIL IN LBS KG IN MM RS13 Hawkweed 1000 0 37 1 151 13CD 2 4 1 09 15 6 396 RS13 Bluebell 1033 5 37 1 170 13CD 2 4 1 09 15 6 396 RS13 Marigold 1113 0 61 1 216 13CD 2 4 1 09 15 6 396 RS14 Hawthorn 1192 5 61 1 258 14CD 3 1 1 41 16 8 427 RS14 — 1250 0 91 1 289 14CD 3 1 1 41 16 8 427 RS14 Narcissus 1272 0 61 1 300 14CD 3 1 1 41 16 8 427 RS14 — 1300 0 91 1 315 14CD 3 1 1 41 16 8 427 RS15 Columbine 1351 5 61 1 340 15CD 3 8 1 72 18 0 457 RS15 Carnation 1431 0 61 1 379 15CD 3 8 1 72 18 0 457 RS15 — 1500 0 91 1 412 15CD 3 8 1 72 18 0 457 RS15 Gladiolus 1510 5 61 1 417 15CD 3 8 1 72 18 0 457 RS16 Coreopsis 1590 0 61 1 454 16CD 4 6 2 09 19 2 488 RS17 Jessamine 1750 0 61 1 525 17CD 5 5 2 49 20 4 518 RS18 Cowslip 2000 0 91 1 630 18CD 6 6 2 99 21 6 549 RS19 Sagebrush 2250 0 91 1 729 19CD 7 8 3 54 22 8 579 RS19 — 2300 0 91 1 750 19CD 7 8 3 54 22 8 579 RS20 Lupine 2500 0 91 1 823 20CD 9 1 4 13 24 0 610 Quick Compress Repair Sleeve for AAC Conductor, RS Series (cont.) 211 Quick Compress ® QuickCompress ® – AAC © 2003, AFL, all rights reserved. PP-3-00759, Revision 3, 3.9.2021 Specifications are subject to change without notice. AFLglobal.com | 800.866.7385 The Quick Compress Jumper Connector is designed for fast and easy installation By using a high strength alloy, the compression length has been shortened for less compression bites The jumper connector is pre-filled, eliminating an installation step Each jumper connector has a center stop, making it easy to center the jumper on the conductor All Quick Compress Jumper Connectors are designed for limited tension use, maintaining a minimum of 40% of the ASTM rated strength of the conductor The end tapers of all compression accessories are supplied with a High Voltage finish for die size sections 12CD and above Ordering Instructions Step 1: Assembly Catalog Number Determine the assembly catalog number based on the conductor being used Example: A jumper connector for 795 Arbutus conductor, the complete catalog number is: JC11 Notes: 1 Installation Instructions for Jumpers are on page 271 2 For more information on die selection and ordering instructions, see Tools and Equipment tab in this catalog Quick Compress Jumper Connector for AAC Conductor, JC Series CATALOG NUMBER CONDUCTOR DIE SIZE TOTAL WEIGHT DIMENSION L CODE WORD SIZE STRANDING DIAMETER KCMIL IN LBS KG IN MM JC07 Peony 300 6 19 0 629 07CD 0 3 0 12 5 6 142 JC07 Tulip 336 4 19 0 666 07CD 0 3 0 12 5 6 142 JC07 Daffodil 350 0 19 0 679 07CD 0 3 0 12 5 6 142 JC08 Canna 397 5 19 0 724 08CD 0 4 0 19 6 4 163 JC09 Goldentuft 450 0 19 0 770 09CD 0 6 0 27 7 2 183 JC09 Cosmos 477 0 19 0 793 09CD 0 6 0 27 7 2 183 JC09 Zinnia 500 0 19 0 811 09CD 0 6 0 27 7 2 183 JC10 Dahlia 556 5 19 0 856 10CD 0 8 0 37 8 0 203 JC10 Meadowsweet 600 0 37 0 891 10CD 0 8 0 37 8 0 203 JC10 Orchid 636 0 37 0 918 10CD 0 8 0 37 8 0 203 JC10 Heuchera 650 0 37 0 928 10CD 0 8 0 37 8 0 203 JC11 Verbena 700 0 37 0 963 11CD 1 1 0 50 8 8 224 JC11 Violet 715 5 37 0 974 11CD 1 1 0 50 8 8 224 JC11 Petunia 750 0 37 0 997 11CD 1 1 0 50 8 8 224 JC11 Arbutus 795 0 37 1 026 11CD 1 1 0 50 8 8 224 JC11 — 800 0 61 1 031 11CD 1 1 0 50 8 8 224 © 2003, AFL, all rights reserved. PP-3-00759, Revision 3, 3.9.2021 Specifications are subject to change without notice. AFLglobal.com | 800.866.7385 212 Quick Compress ® QuickCompress ® – AAC CATALOG NUMBER CONDUCTOR DIE SIZE TOTAL WEIGHT DIMENSION L CODE WORD SIZE STRANDING DIAMETER KCMIL IN LBS KG IN MM JC12 Cockscomb 900 0 37 1 092 12CD 1 4 0 64 9 6 244 JC12 Magnolia 954 0 37 1 124 12CD 1 4 0 64 9 6 244 JC13 Hawkweed 1000 0 37 1 151 13CD 1 7 0 77 10 4 264 JC13 Bluebell 1033 5 37 1 170 13CD 1 7 0 77 10 4 264 JC13 Marigold 1113 0 61 1 216 13CD 1 7 0 77 10 4 264 JC14 Hawthorn 1192 5 61 1 258 14CD 2 2 1 00 11 2 284 JC14 — 1250 0 91 1 289 14CD 2 2 1 00 11 2 284 JC14 Narcissus 1272 0 61 1 300 14CD 2 2 1 00 11 2 284 JC14 — 1300 0 91 1 315 14CD 2 2 1 00 11 2 284 JC15 Columbine 1351 5 61 1 340 15CD 2 7 1 22 12 0 305 JC15 Carnation 1431 0 61 1 379 15CD 2 7 1 22 12 0 305 JC15 — 1500 0 91 1 412 15CD 2 7 1 22 12 0 305 JC15 Gladiolus 1510 5 61 1 417 15CD 2 7 1 22 12 0 305 JC16 Coreopsis 1590 0 61 1 454 16CD 3 3 1 50 12 8 325 JC17 Jessamine 1750 0 61 1 525 17CD 3 9 1 77 13 6 345 JC18 Cowslip 2000 0 91 1 630 18CD 4 7 2 13 14 4 366 JC19 Sagebrush 2250 0 91 1 729 19CD 5 4 2 45 15 2 386 JC19 — 2300 0 91 1 750 19CD 5 4 2 45 15 2 386 JC20 Lupine 2500 0 91 1 823 20CD 6 4 2 90 16 0 406 Quick Compress Jumper Connector for AAC Conductor, JC Series (cont.) 213 Quick Compress ® QuickCompress ® – AAC © 2003, AFL, all rights reserved. PP-3-00759, Revision 3, 3.9.2021 Specifications are subject to change without notice. AFLglobal.com | 800.866.7385 The TS Series Straight Terminal Connector is designed for fast and easy installation By using a high strength alloy, the compression length has been shortened for less compression bites The terminal connector is pre-filled, eliminating an installation step All TS Series connectors are designed for limited tension use, maintaining a minimum of 40% of the ASTM rated strength of the conductor The end tapers of all compression accessories are supplied with a High Voltage finish for die size sections 12CD and above The square edges of bolted pads of the compression accessories could cause Corona Pads with edges and corners rounded can be supplied by adding the catalog suffix 'EHV' Ordering Instructions Step 1: Catalog Number Determine the catalog number based on the conductor being used Step 2: Extra High Voltage Finish For Extra High Voltage Finish, use 'EHV' ( ≥ 345 kV) For Standard Finish, leave blank ( < 345 kV) Step 3: Assemble Catalog Number. Example: A straight terminal for 795 Arbutus with an EHV finish, the complete catalog number is: TS11EHV Catalog Number EHV Finish + Notes: 1 Pad Dimensions are on page 257 2 Installation Instructions for Terminals are on page 272 3 Bolts, nuts and washers are not supplied with TS Series Terminal Connectors 4 For more information on die selection and ordering instructions, see Tools and Equipment tab in this catalog Quick Compress Terminal for AAC Conductor, Straight, TS Series © 2003, AFL, all rights reserved. PP-3-00759, Revision 3, 3.9.2021 Specifications are subject to change without notice. AFLglobal.com | 800.866.7385 214 Quick Compress ® QuickCompress ® – AAC Quick Compress Terminal for AAC Conductor, Straight, TS Series (cont.) CATALOG NUMBER CONDUCTOR DIE SIZE TOTAL WEIGHT DIMENSION PAD SIZE CODE WORD SIZE STRANDING DIAMETER A L KCMIL AL IN LBS KG IN MM IN MM TS07 Peony 300 0 19 0 629 07CD 0 5 0 20 0 3 8 9 0 229 B TS07 Tulip 336 4 19 0 666 07CD 0 5 0 20 0 3 8 9 0 229 B TS07 Daffodil 350 0 19 0 679 07CD 0 5 0 20 0 3 8 9 0 229 B TS08 Canna 397 5 19 0 724 08CD 0 6 0 28 0 4 10 9 6 244 B TS09 Goldentuft 450 0 19 0 770 09CD 0 8 0 38 0 4 11 10 0 254 B TS09 Cosmos 477 0 19 0 793 09CD 0 8 0 38 0 4 11 10 0 254 B TS09 Zinnia 500 0 19 0 811 09CD 0 8 0 38 0 4 11 10 0 254 B TS10 Dahlia 556 5 19 0 856 10CD 1 1 0 50 0 5 12 10 6 269 B TS10 Meadowsweet 600 0 37 0 891 10CD 1 1 0 50 0 5 12 10 6 269 B TS10 Orchid 636 0 37 0 918 10CD 1 1 0 50 0 5 12 10 6 269 B TS10 Heuchera 650 0 37 0 928 10CD 1 1 0 50 0 5 12 10 6 269 B TS11 Verbena 700 0 37 0 963 11CD 1 5 0 68 0 4 9 11 7 297 D TS11 Violet 715 5 37 0 974 11CD 1 5 0 68 0 4 9 11 7 297 D TS11 Petunia 750 0 37 0 997 11CD 1 5 0 68 0 4 9 11 7 297 D TS11 Arbutus 795 0 37 1 026 11CD 1 5 0 68 0 4 9 11 7 297 D TS11 — 800 0 61 1 031 11CD 1 5 0 68 0 4 9 11 7 297 D TS12 Cockscomb 900 0 37 1 092 12CD 1 8 0 82 0 4 11 12 1 307 D TS12 Magnolia 954 0 37 1 124 12CD 1 8 0 82 0 4 11 12 1 307 D TS13 Hawkweed 1000 0 37 1 151 13CD 2 1 0 95 0 5 13 12 8 325 D TS13 Bluebell 1033 5 37 1 170 13CD 2 1 0 95 0 5 13 12 8 325 D TS13 Marigold 1113 0 61 1 216 13CD 2 1 0 95 0 5 13 12 8 325 D TS14 Hawthorn 1192 5 61 1 258 14CD 2 7 1 22 0 6 16 13 8 351 D TS14 — 1250 0 91 1 289 14CD 2 7 1 22 0 6 16 13 8 351 D TS14 Narcissus 1272 0 61 1 300 14CD 2 7 1 22 0 6 16 13 8 351 D TS14 — 1300 0 91 1 315 14CD 2 7 1 22 0 6 16 13 8 351 D TS15 Columbine 1351 5 61 1 340 15CD 3 3 1 50 0 7 17 14 3 363 D TS15 Carnation 1431 0 61 1 379 15CD 3 3 1 50 0 7 17 14 3 363 D TS15 — 1500 0 91 1 412 15CD 3 3 1 50 0 7 17 14 3 363 D TS15 Gladiolus 1510 5 61 1 417 15CD 3 3 1 50 0 7 17 14 3 363 D TS16 Coreopsis 1590 0 61 1 454 16CD 3 8 1 72 0 7 17 14 6 371 D TS17 Jessamine 1750 0 61 1 525 17CD 0 5 2 13 0 7 17 16 3 414 E TS18 Cowslip 2000 0 91 1 630 18CD 5 5 2 49 0 7 19 16 8 427 E TS19 Sagebrush 2250 0 91 1 729 19CD 6 5 2 95 0 9 22 17 5 445 E TS19 — 2300 0 91 1 750 19CD 6 5 2 95 0 9 22 17 5 445 E TS20 Lupine 2500 0 91 1 823 20CD 7 3 3 31 0 9 22 12 9 455 E 215 Quick Compress ® QuickCompress ® – AAC © 2003, AFL, all rights reserved. PP-3-00759, Revision 3, 3.9.2021 Specifications are subject to change without notice. AFLglobal.com | 800.866.7385 The TF Series 15º Terminal Connector is designed for fast and easy installation By using a high strength alloy, the compression length has been shortened for less compression bites The termi - nal connector is pre-filled, eliminating an installation step When used with the Quick Compress dead end, the TF Series connectors can be bolted in either straight or 30º position All TF Series connectors are designed for limited tension use, maintaining a minimum of 40% of the ASTM rated strength of the conductor The end tapers of all compression accessories are supplied with a High Voltage finish for die size sections 12CD and above The square edges of bolted pads of the compression accessories could cause Corona Pads with edges and corners rounded can be supplied by adding the catalog suffix 'EHV' Ordering Instructions Step 1: Catalog Number Determine the catalog number based on the conductor being used Step 2: Extra High Voltage Finish For Extra High Voltage Finish, use 'EHV' ( ≥ 345 kV) For Standard Finish, leave blank ( < 345 kV) Step 3: Assemble Catalog Number. Example: A 15º terminal for 795 Arbutus with an EHV finish, the complete catalog number is: TF11EHV Catalog Number EHV Finish + Notes: 1 Pad Dimensions are on page 257 2 Installation Instructions for Terminals are on page 272 3 Bolts, nuts and washers are supplied with TF Series Terminal Connectors 4 For more information on die selection and ordering instructions, see Tools and Equipment tab in this catalog Quick Compress Terminal for AAC Conductor, 15º, TF Series © 2003, AFL, all rights reserved. PP-3-00759, Revision 3, 3.9.2021 Specifications are subject to change without notice. AFLglobal.com | 800.866.7385 216 Quick Compress ® QuickCompress ® – AAC Quick Compress Terminal for AAC Conductor, 15º, TF Series (cont.) CATALOG NUMBER CONDUCTOR DIE SIZE TOTAL WEIGHT DIMENSIONS PAD SIZE CODE WORD SIZE STRANDING DIAMETER A L KCMIL AL/ST IN LBS KG IN MM IN MM TF07 Peony 300 6 19 0 629 07CD 0 5 0 24 0 3 8 7 8 196 B TF07 Tulip 336 4 19 0 666 07CD 0 5 0 24 0 3 8 7 8 196 B TF07 Daffodil 350 0 19 0 679 07CD 0 5 0 24 0 3 8 7 8 196 B TF08 Canna 397 5 19 0 724 08CD 0 7 0 31 0 4 10 8 3 211 B TF09 Goldentuft 450 0 19 0 770 09CD 0 9 0 40 0 4 11 8 9 226 B TF09 Cosmos 477 0 19 0 793 09CD 0 9 0 40 0 4 11 8 9 226 B TF09 Zinnia 500 0 19 0 811 09CD 0 9 0 40 0 4 11 8 9 226 B TF10 Dahlia 556 5 19 0 856 10CD 1 1 0 50 0 5 12 9 4 239 B TF10 Meadowsweet 600 0 37 0 891 10CD 1 1 0 50 0 5 12 9 4 239 B TF10 Orchid 636 0 37 0 918 10CD 1 1 0 50 0 5 12 9 4 239 B TF10 Heuchera 650 0 37 0 928 10CD 1 1 0 50 0 5 12 9 4 239 B TF11 Verbena 700 0 37 0 963 11CD 1 5 0 68 0 4 9 10 4 264 D TF11 Violet 715 5 37 0 974 11CD 1 5 0 68 0 4 9 10 4 264 D TF11 Petunia 750 0 37 0 997 11CD 1 5 0 68 0 4 9 10 4 264 D TF11 Arbutus 795 0 37 1 026 11CD 1 5 0 68 0 4 9 10 4 264 D TF11 — 800 0 61 1 031 11CD 1 5 0 68 0 4 9 10 4 264 D TF12 Cockscomb 900 0 37 1 092 12CD 1 9 0 86 0 4 11 11 0 279 D TF12 Magnolia 954 0 37 1 124 12CD 1 9 0 86 0 4 11 11 0 279 D TF13 Hawkweed 1000 0 37 1 151 13CD 2 2 1 00 0 5 13 11 2 284 D TF13 Bluebell 1033 5 37 1 170 13CD 2 2 1 00 0 5 13 11 2 284 D TF13 Marigold 1113 0 61 1 216 13CD 2 2 1 00 0 5 13 11 2 284 D TF14 Hawthorn 1192 5 61 1 258 14CD 2 8 1 27 0 6 16 12 0 305 D TF14 — 1250 0 91 1 289 14CD 2 8 1 27 0 6 16 12 0 305 D TF14 Narcissus 1272 0 61 1 300 14CD 2 8 1 27 0 6 16 12 0 305 D TF14 — 1300 0 91 1 315 14CD 2 8 1 27 0 6 16 12 0 305 D TF15 Columbine 1351 5 61 1 340 15CD 3 2 1 45 0 7 17 12 5 318 D TF15 Carnation 1431 0 61 1 379 15CD 3 2 1 45 0 7 17 12 5 318 D TF15 — 1500 0 91 1 412 15CD 3 2 1 45 0 7 17 12 5 318 D TF15 Gladiolus 1510 5 61 1 417 15CD 3 2 1 45 0 7 17 12 5 318 D TF16 Coreopsis 1590 0 61 1 454 16CD 3 7 1 69 0 9 17 13 3 338 D TF17 Jessamine 1750 0 61 1 525 17CD 4 6 2 09 0 7 17 14 4 366 E TF18 Cowslip 2000 0 91 1 630 18CD 5 2 2 36 0 7 19 15 0 381 E TF19 Sagebrush 2250 0 91 1 729 19CD 6 3 2 86 0 9 22 15 7 399 E TF19 — 2300 0 91 1 750 19CD 6 3 2 86 0 9 22 15 7 399 E TF20 Lupine 2500 0 91 1 823 20CD 6 8 3 08 0 9 22 16 0 406 E 217 Quick Compress ® QuickCompress ® – AAC © 2003, AFL, all rights reserved. PP-3-00759, Revision 3, 3.9.2021 Specifications are subject to change without notice. AFLglobal.com | 800.866.7385 The T45 Series 45º Terminal Connector is designed for fast and easy installation By using a high strength alloy, the compression length has been shortened for less compression bites The terminal connector is pre-filled, eliminating an installation step All T45 Series connectors are designed for limited tension use, maintaining a minimum of 40% of the ASTM rated strength of the conductor The end tapers of all compression accessories are supplied with a High Voltage finish for die size sections 12CD and above The square edges of bolted pads of the compression accessories could cause Corona Pads with edges and corners rounded can be supplied by adding the catalog suffix 'EHV' Ordering Instructions Step 1: Catalog Number Determine the catalog number based on the conductor being used Step 2: Extra High Voltage Finish For Extra High Voltage Finish, use 'EHV' ( ≥ 345 kV) For Standard Finish, leave blank ( < 345 kV) Step 3: Assemble Catalog Number. Example: A 45º terminal for 795 Arbutus with an EHV finish, the complete catalog number is: T4511EHV Catalog Number EHV Finish + Notes: 1 Pad Dimensions are on page 257 2 Installation Instructions for Terminals are on page 272 3 Bolts, nuts and washers are not supplied with T45 Series Terminal Connectors 4 For more information on die selection and ordering instructions, see Tools and Equipment tab in this catalog Quick Compress Terminal for AAC Conductor, 45º, T45 Series © 2003, AFL, all rights reserved. PP-3-00759, Revision 3, 3.9.2021 Specifications are subject to change without notice. AFLglobal.com | 800.866.7385 218 Quick Compress ® QuickCompress ® – AAC Quick Compress Terminal for AAC Conductor, 45º, T45 Series (cont.) CATALOG NUMBER CONDUCTOR DIE SIZE TOTAL WEIGHT DIMENSIONS PAD SIZE CODE WORD SIZE STRANDING DIAMETER A L KCMIL AL/ST IN LBS KG IN MM IN MM T4507 Peony 300 6 19 0 629 07CD 0 4 0 19 0 3 8 7 3 185 B T4507 Tulip 336 4 19 0 666 07CD 0 4 0 19 0 3 8 7 3 185 B T4507 Daffodil 350 0 19 0 679 07CD 0 4 0 19 0 3 8 7 3 185 B T4508 Canna 397 5 19 0 724 08CD 0 6 0 25 0 4 10 7 8 198 B T4509 Goldentuft 450 0 19 0 770 09CD 0 8 0 34 0 4 11 8 2 208 B T4509 Cosmos 477 0 19 0 793 09CD 0 8 0 34 0 4 11 8 2 208 B T4509 Zinnia 500 0 19 0 811 09CD 0 8 0 34 0 4 11 8 2 208 B T4510 Dahlia 556 5 19 0 856 10CD 1 0 0 45 0 5 12 8 6 218 B T4510 Meadowsweet 600 0 37 0 891 10CD 1 0 0 45 0 5 12 8 6 218 B T4510 Orchid 636 0 37 0 918 10CD 1 0 0 45 0 5 12 8 6 218 B T4510 Heuchera 650 0 37 0 928 10CD 1 0 0 45 0 5 12 8 6 218 B T4511 Verbena 700 0 37 0 963 11CD 1 3 0 59 0 4 9 9 4 239 D T4511 Violet 715 5 37 0 974 11CD 1 3 0 59 0 4 9 9 4 239 D T4511 Petunia 750 0 37 0 997 11CD 1 3 0 59 0 4 9 9 4 239 D T4511 Arbutus 795 0 37 1 026 11CD 1 3 0 59 0 4 9 9 4 239 D T4511 — 800 0 61 1 031 11CD 1 3 0 59 0 4 9 9 4 239 D T4512 Cockscomb 900 0 37 1 092 12CD 1 6 0 73 0 4 11 9 7 246 D T4512 Magnolia 954 0 37 1 124 12CD 1 6 0 73 0 4 11 9 7 246 D T4513 Hawkweed 1000 0 37 1 151 13CD 2 0 0 91 0 5 13 10 2 259 D T4513 Bluebell 1033 5 37 1 170 13CD 2 0 0 91 0 5 13 10 2 259 D T4513 Marigold 1113 0 61 1 216 13CD 2 0 0 91 0 5 13 10 2 259 D T4514 Hawthorn 1192 5 61 1 258 14CD 2 3 1 04 0 6 16 10 6 269 D T4514 — 1250 0 91 1 289 14CD 2 3 1 04 0 6 16 10 6 269 D T4514 Narcissus 1272 0 61 1 300 14CD 2 3 1 04 0 6 16 10 6 269 D T4514 — 1300 0 91 1 315 14CD 2 3 1 04 0 6 16 10 6 269 D T4515 Columbine 1351 5 61 1 340 15CD 2 8 1 27 0 7 17 11 8 300 D T4515 Carnation 1431 0 61 1 379 15CD 2 8 1 27 0 7 17 11 8 300 D T4515 — 1500 0 91 1 412 15CD 2 8 1 27 0 7 17 11 8 300 D T4515 Gladiolus 1510 5 61 1 417 15CD 2 8 1 27 0 7 17 11 8 300 D T4516 Coreopsis 1590 0 61 1 454 16CD 3 4 1 54 0 7 17 11 0 279 D T4517 Jessamine 1750 0 61 1 525 17CD 4 2 1 91 0 7 17 12 6 320 E T4518 Cowslip 2000 0 91 1 630 18CD 4 9 2 22 0 7 19 13 0 330 E T4519 Sagebrush 2250 0 91 1 729 19CD 5 7 2 59 0 9 22 13 7 348 E T4519 — 2300 0 91 1 750 19CD 5 7 2 59 0 9 22 13 7 348 E T4520 Lupine 2500 0 91 1 823 20CD 6 5 2 95 0 9 22 14 2 361 E 219 Quick Compress ® QuickCompress ® – AAC © 2003, AFL, all rights reserved. PP-3-00759, Revision 3, 3.9.2021 Specifications are subject to change without notice. AFLglobal.com | 800.866.7385 The TN Series 90º Terminal Connector is designed for fast and easy installation By using a high strength alloy, the compression length has been shortened for less compression bites The termi - nal connector is pre-filled, eliminating an installation step All TN Series connectors are designed for limited tension use, maintaining a minimum of 40% of the ASTM rated strength of the conductor The end tapers of all compression accessories are supplied with a High Voltage finish for die size sections 12CD and above The square edges of bolted pads of the compression accessories could cause Corona Pads with edges and corners rounded can be supplied by adding the catalog suffix 'EHV' Ordering Instructions Step 1: Catalog Number Determine the catalog number based on the conductor being used Step 2: Extra High Voltage Finish For Extra High Voltage Finish, use 'EHV' ( ≥ 345 kV) For Standard Finish, leave blank ( < 345 kV) Step 3: Assemble Catalog Number. Example: A 90º terminal for 795 Arbutus with an EHV finish, the complete catalog number is: TN11EHV Catalog Number EHV Finish + Notes: 1 Pad Dimensions are on page 257 2 Installation Instructions for Terminals are on page 272 3 Bolts, nuts and washers are not supplied with TN Series Terminal Connectors 4 For more information on die selection and ordering instructions, see Tools and Equipment tab in this catalog Quick Compress Terminal for AAC Conductor, 90º, TN Series © 2003, AFL, all rights reserved. PP-3-00759, Revision 3, 3.9.2021 Specifications are subject to change without notice. AFLglobal.com | 800.866.7385 220 Quick Compress ® QuickCompress ® – AAC Quick Compress Terminal for AAC Conductor, 90º, TN Series (cont.) CATALOG NUMBER CONDUCTOR DIE SIZE TOTAL WEIGHT DIMENSIONS PAD SIZE CODE WORD SIZE STRANDING DIAMETER A L KCMIL AL IN LBS KG IN MM IN MM TN07 Peony 300 6 19 0 629 07CD 0 5 0 20 0 3 8 5 2 132 B TN07 Tulip 336 4 19 0 666 07CD 0 5 0 20 0 3 8 5 2 132 B TN07 Daffodil 350 0 19 0 679 07CD 0 5 0 20 0 3 8 5 2 132 B TN08 Canna 397 5 19 0 724 08CD 0 6 0 29 0 4 10 5 7 145 B TN09 Goldentuft 450 0 19 0 770 09CD 0 8 0 38 0 4 11 6 2 157 B TN09 Cosmos 477 0 19 0 793 09CD 0 8 0 38 0 4 11 6 2 157 B TN09 Zinnia 500 0 19 0 811 09CD 0 8 0 38 0 4 11 6 2 157 B TN10 Dahlia 556 5 19 0 856 10CD 1 1 0 50 0 5 12 6 7 170 B TN10 Meadowsweet 600 0 37 0 891 10CD 1 1 0 50 0 5 12 6 7 170 B TN10 Orchid 636 0 37 0 918 10CD 1 1 0 50 0 5 12 6 7 170 B TN10 Heuchera 650 0 37 0 928 10CD 1 1 0 50 0 5 12 6 7 170 B TN11 Verbena 700 0 37 0 963 11CD 1 4 0 64 0 4 9 7 5 191 D TN11 Violet 715 5 37 0 974 11CD 1 4 0 64 0 4 9 7 5 191 D TN11 Petunia 750 0 37 0 997 11CD 1 4 0 64 0 4 9 7 5 191 D TN11 Arbutus 795 0 37 1 026 11CD 1 4 0 64 0 4 9 7 5 191 D TN11 — 800 0 61 1 031 11CD 1 4 0 64 0 4 9 7 5 191 D TN12 Cockscomb 900 0 37 1 092 12CD 1 8 0 82 0 4 11 7 9 202 D TN12 Magnolia 954 0 37 1 124 12CD 1 8 0 82 0 4 11 7 9 202 D TN13 Hawkweed 1000 0 37 1 151 13CD 2 2 1 00 0 5 13 8 5 216 D TN13 Bluebell 1033 5 37 1 170 13CD 2 2 1 00 0 5 13 8 5 216 D TN13 Marigold 1113 0 61 1 216 13CD 2 2 1 00 0 5 13 8 5 216 D TN14 Hawthorn 1192 5 61 1 258 14CD 2 6 1 18 0 6 16 9 2 233 D TN14 — 1250 0 91 1 289 14CD 2 6 1 18 0 6 16 9 2 233 D TN14 Narcissus 1272 0 61 1 300 14CD 2 6 1 18 0 6 16 9 2 233 D TN14 — 1300 0 91 1 315 14CD 2 6 1 18 0 6 16 9 2 233 D TN15 Columbine 1351 5 61 1 340 15CD 3 1 1 41 0 7 17 9 8 248 D TN15 Carnation 1431 0 61 1 379 15CD 3 1 1 41 0 7 17 9 8 248 D TN15 — 1500 0 91 1 412 15CD 3 1 1 41 0 7 17 9 8 248 D TN15 Gladiolus 1510 5 61 1 417 15CD 3 1 1 41 0 7 17 9 8 248 D TN16 Coreopsis 1590 0 61 1 454 16CD 3 7 1 68 0 7 17 10 2 259 D TN17 Jessamine 1750 0 61 1 525 17CD 4 6 2 09 0 7 17 11 2 264 E TN18 Cowslip 2000 0 91 1 630 18CD 5 3 2 40 0 7 19 11 4 289 E TN19 Sagebrush 2250 0 91 1 729 19CD 6 1 2 77 0 9 22 11 9 303 E TN19 — 2300 0 91 1 750 19CD 6 1 2 77 0 9 22 11 9 303 E TN20 Lupine 2500 0 91 1 823 20CD 6 9 3 13 0 9 22 12 6 321 E 221 Quick Compress ® QuickCompress ® – AAC © 2003, AFL, all rights reserved. PP-3-00759, Revision 3, 3.9.2021 Specifications are subject to change without notice. AFLglobal.com | 800.866.7385 The TTOC Series Open Run Tee Connector is a permanent drop specifically desgined for ACSR, AAC, AAAC and ACAR conductors The end tapers of all compression accessories are supplied with a high voltage finish for die size sections 12CD and above Ordering Instructions Step 1: Assembly Catalog Number Determine the assembly catalog number based on the conductor being used Example: A tee connector for 795 Arbutus, the complete catalog number is: TTOC11 Notes: 1 Tee Connectors are not prefilled with AFC 2 Installation Instructions for Tee Connectors are on page 274 3 For more information on die selection and ordering instructions, see Tools and Equipment tab in this catalog Quick Compress Tee Connector for AAC Conductor, Open Run, TTOC Series CATALOG NUMBER CONDUCTOR DIE SIZE TOTAL WEIGHT DIMENSIONS CODE WORD SIZE STRANDING DIAMETER A L KCMIL AL IN LBS KG IN MM IN MM TTOC07 Peony 300 0 19 0 629 07CD 0 5 0 22 3 9 100 6 4 163 TTOC07 Tulip 336 4 19 0 666 07CD 0 5 0 22 3 9 100 6 4 163 TTOC07 Daffodil 350 0 19 0 679 07CD 0 5 0 22 3 9 100 6 4 163 TTOC08 Canna 397 5 19 0 724 08CD 0 7 0 32 4 4 111 7 2 183 TTOC08 Goldentuft 450 0 19 0 770 08CD 0 7 0 32 4 4 111 7 2 183 TTOC09 Cosmos 477 0 19 0 793 09CD 1 0 0 45 4 8 122 7 9 199 TTOC09 Zinnia 500 0 19 0 811 09CD 1 0 0 45 4 8 122 7 9 199 TTOC10 Dahlia 556 5 19 0 856 10CD 1 3 0 59 5 3 133 8 5 216 TTOC10 Meadowsweet 600 0 37 0 891 10CD 1 3 0 59 5 3 133 8 5 216 TTOC10 Orchid 636 0 37 0 918 10CD 1 3 0 59 5 3 133 8 5 216 TTOC10 Heuchera 650 0 37 0 928 10CD 1 3 0 59 5 3 133 8 5 216 TTOC11 Verbena 700 0 37 0 963 11CD 1 7 0 77 5 7 145 9 2 234 TTOC11 Violet 715 5 37 0 974 11CD 1 7 0 77 5 7 145 9 2 234 TTOC11 Petunia 750 0 37 0 997 11CD 1 7 0 77 5 7 145 9 2 234 TTOC11 Arbutus 795 0 37 1 026 11CD 1 7 0 77 5 7 145 9 2 234 TTOC11 — 800 0 61 1 031 11CD 1 7 0 77 5 7 145 9 2 234 TTOP12 Cockscomb 900 0 37 1 092 12CD 2 1 0 95 6 1 155 9 9 250 © 2003, AFL, all rights reserved. PP-3-00759, Revision 3, 3.9.2021 Specifications are subject to change without notice. AFLglobal.com | 800.866.7385 222 Quick Compress ® QuickCompress ® – AAC CATALOG NUMBER CONDUCTOR DIE SIZE TOTAL WEIGHT DIMENSIONS CODE WORD SIZE STRANDING DIAMETER A L KCMIL AL IN LBS KG IN MM IN MM TTOC12 Magnolia 954 0 37 1 124 12CD 2 1 0 95 6 1 155 9 9 250 TTOC13 Hawkweed 1000 0 37 1 151 13CD 2 9 1 32 6 6 167 10 6 269 TTOC13 Bluebell 1033 5 37 1 170 13CD 2 9 1 32 6 6 167 10 6 269 TTOC13 Marigold 1113 0 61 1 216 13CD 2 9 1 32 6 6 167 10 6 269 TTOC14 Hawthorn 1192 5 61 1 258 14CD 3 5 1 59 7 0 178 11 2 285 TTOC14 — 1250 0 91 1 289 14CD 3 5 1 59 7 0 178 11 2 285 TTOC14 Narcissus 1272 0 61 1 300 14CD 3 5 1 59 7 0 178 11 2 285 TTOC14 — 1300 0 91 1 315 14CD 3 5 1 59 7 0 178 11 2 285 TTOC15 Columbine 1351 5 61 1 340 15CD 4 2 1 91 7 4 189 11 9 302 TTOC15 Carnation 1431 0 61 1 379 15CD 4 2 1 91 7 4 189 11 9 302 TTOC15 — 1500 0 91 1 412 15CD 4 2 1 91 7 4 189 11 9 302 TTOC15 Gladiolus 1510 5 61 1 417 15CD 4 2 1 91 7 4 189 11 9 302 TTOC16 Coreopsis 1590 0 61 1 454 16CD 5 0 2 27 7 8 198 12 5 316 TTOC17 Jessamine 1750 0 61 1 525 17CD 5 9 2 68 8 3 210 13 1 333 TTOC18 Cowslip 2000 0 91 1 630 18CD 7 0 3 16 8 6 219 13 7 348 TTOC19 Sagebrush 2250 0 91 1 729 19CD 8 0 3 63 9 1 230 14 4 364 TTOC19 — 2300 0 91 1 750 19CD 8 0 3 63 9 1 230 14 4 364 TTOC20 Lupine 2500 0 91 1 823 20CD 9 2 4 17 9 4 240 14 9 378 Quick Compress Tee Connector for AAC Conductor, Open Run, TTOC Series (cont.) 223 Quick Compress ® QuickCompress ® – AAC © 2003, AFL, all rights reserved. PP-3-00759, Revision 3, 3.9.2021 Specifications are subject to change without notice. AFLglobal.com | 800.866.7385 The TTOP Series Open Run Tee Tap is a permanent or temporary drop By using a high strength alloy, the compression length has been shortened for less compression bites The run portion incorporates an improved design of interlock - ing extrusions, providing a permanent grip on the conductor when compressed The end tapers of all compression accessories are supplied with a High Voltage finish for die size sections 12CD and above The square edges of bolted pads of the compression accessories could cause Corona Pads with edges and corners rounded can be supplied by adding the catalog suffix 'EHV' Quick Compress Tee Tap for AAC Conductor, Open Run, TTOP Series Ordering Instructions Step 1: Assembly Catalog Number Determine the assembly catalog number based on the conductor being used Step 2: Extra High Voltage Finish For Extra High Voltage Finish, use 'EHV' ( ≥ 345 kV) For Standard Finish, leave blank ( < 345 kV) Step 3: Assemble Catalog Number. Example: A tee tap for 795 Arbutus with EHV finish, the complete catalog number is: TTOP11EHV Assy Catalog Number EHV Finish + Notes: 1 Installation Instructions for Tee Taps are on page 274 2 For more information on die selection and ordering instructions, see Tools and Equipment tab in this catalog © 2003, AFL, all rights reserved. PP-3-00759, Revision 3, 3.9.2021 Specifications are subject to change without notice. AFLglobal.com | 800.866.7385 224 Quick Compress ® QuickCompress ® – AAC Quick Compress Tee Tap for AAC Conductor, Open Run, TTOP Series (cont.) CATALOG NUMBER CONDUCTOR DIE SIZE WEIGHT DIMENSIONS PAD SIZE CODE WORD SIZE STRANDING DIAMETER ALUMINUM A L AB KCMIL AL/ST IN LBS KG IN MM IN MM IN MM TTOP07 Peony 300 6 19 0 629 07CD 0 6 0 27 0 4 10 7 4 187 2 0 51 B TTOP07 Tulip 336 4 19 0 666 07CD 0 6 0 27 0 4 10 7 4 187 2 0 51 B TTOP07 Daffodil 350 0 19 0 679 07CD 0 6 0 27 0 4 10 7 4 187 2 0 51 B TTOP08 Canna 397 5 19 0 724 08CD 0 7 0 34 0 4 10 8 0 202 2 0 51 B TTOP09 Goldentuft 450 0 19 0 770 09CD 0 9 0 41 0 4 10 8 5 215 2 0 51 B TTOP09 Cosmos 477 0 19 0 793 09CD 0 9 0 41 0 4 10 8 5 215 2 0 51 B TTOP09 Zinnia 500 0 19 0 811 09CD 0 9 0 41 0 4 10 8 5 215 2 0 51 B TTOP10 Dahlia 556 5 19 0 856 10CD 1 0 0 45 0 4 10 9 0 229 2 0 51 B TTOP10 Meadowsweet 600 0 37 0 891 10CD 1 0 0 45 0 4 10 9 0 229 2 0 51 B TTOP10 Orchid 636 0 37 0 918 10CD 1 0 0 45 0 4 10 9 0 229 2 0 51 B TTOP10 Heuchera 650 0 37 0 928 10CD 1 0 0 45 0 4 10 9 0 229 2 0 51 B TTOP11 Verbena 700 0 37 0 963 11CD 1 7 0 77 0 5 13 10 5 267 3 0 76 D TTOP11 Violet 715 5 37 0 974 11CD 1 7 0 77 0 5 13 10 5 267 3 0 76 D TTOP11 Petunia 750 0 37 0 997 11CD 1 7 0 77 0 5 13 10 5 267 3 0 76 D TTOP11 Arbutus 795 0 37 1 026 11CD 1 7 0 77 0 5 13 10 5 267 3 0 76 D TTOP11 — 800 0 61 1 031 11CD 1 7 0 77 0 5 13 10 5 267 3 0 76 D TTOP12 Cockscomb 900 0 37 1 092 12CD 2 0 0 91 0 5 13 11 1 281 3 0 76 D TTOP12 Magnolia 954 0 37 1 124 12CD 2 0 0 91 0 5 13 11 1 281 3 0 76 D TTOP13 Hawkweed 1000 0 37 1 151 13CD 2 4 1 09 0 5 13 11 6 294 3 0 76 D TTOP13 Bluebell 1033 5 37 1 170 13CD 2 4 1 09 0 5 13 11 6 294 3 0 76 D TTOP13 Marigold 1113 0 61 1 216 13CD 2 4 1 09 0 5 13 11 6 294 3 0 76 D TTOP14 Hawthorn 1192 5 61 1 258 14CD 2 8 1 27 0 5 13 12 1 307 3 0 76 D TTOP14 — 1250 0 91 1 289 14CD 2 8 1 27 0 5 13 12 1 307 3 0 76 D TTOP14 Narcissus 1272 0 61 1 300 14CD 2 8 1 27 0 5 13 12 1 307 3 0 76 D TTOP14 — 1300 0 91 1 315 14CD 2 8 1 27 0 5 13 12 1 307 3 0 76 D TTOP15 Columbine 1351 5 61 1 340 15CD 3 3 1 50 0 5 13 12 6 321 3 0 76 D TTOP15 Carnation 1431 0 61 1 379 15CD 3 3 1 50 0 5 13 12 6 321 3 0 76 D TTOP15 — 1500 0 91 1 412 15CD 3 3 1 50 0 5 13 12 6 321 3 0 76 D TTOP15 Gladiolus 1510 5 61 1 417 15CD 3 3 1 50 0 5 13 12 6 321 3 0 76 D TTOP16 Coreopsis 1590 0 61 1 454 16CD 3 7 1 68 0 5 13 13 2 334 3 0 76 D TTOP17 Jessamine 1750 0 61 1 525 17CD 5 2 2 36 0 8 19 14 6 370 4 0 102 E TTOP18 Cowslip 2000 0 91 1 630 18CD 5 9 2 68 0 8 19 15 0 380 4 0 102 E TTOP19 Sagebrush 2250 0 91 1 729 19CD 6 5 2 95 0 8 19 15 5 393 4 0 102 E TTOP19 — 2300 0 91 1 750 19CD 6 5 2 95 0 8 19 15 5 393 4 0 102 E TTOP20 Lupine 2500 0 91 1 823 20CD 7 2 3 27 0 8 19 15 9 403 4 0 102 E
