241 Quick Compress ® QuickCompress ® – AAAC & ACAR © 2003, AFL, all rights reserved. PP-3-00758, Revision 3, 3.9.2021 Specifications are subject to change without notice. AFLglobal.com | 800.866.7385 The TS Series Straight Terminal Connector is designed for fast and easy installation By using a high strength alloy, the compression length has been shortened for less compression bites The terminal connector is pre-filled, eliminating an installation step All TS Series connectors are designed for limited tension use, maintaining a minimum of 40% of the ASTM rated strength of the conductor The end tapers of all compression accessories are supplied with a High Voltage finish for die size sections 12CD and above The square edges of bolted pads of the compression accessories could cause Corona Pads with edges and corners rounded can be supplied by adding the catalog suffix 'EHV' Ordering Instructions Step 1: Catalog Number Determine the catalog number based on the conductor being used Step 2: Extra High Voltage Finish For Extra High Voltage Finish, use 'EHV' ( ≥ 345 kV) For Standard Finish, leave blank ( < 345 kV) Step 3: Assemble Catalog Number. Example: A straight terminal for 927 7 Greeley with an EHV finish, the complete catalog number is: TS12EHV Catalog Number EHV Finish + Notes: 1 Pad Dimensions are on page 257 2 Installation Instructions for Terminals are on page 272 3 Bolts, nuts and washers are not supplied with TS Series Terminal Connectors 4 For more information on die selection and ordering instructions, see Tools and Equipment tab in this catalog Quick Compress Terminal for AAAC and ACAR Conductor, Straight, TS Series © 2003, AFL, all rights reserved. PP-3-00758, Revision 3, 3.9.2021 Specifications are subject to change without notice. AFLglobal.com | 800.866.7385 242 Quick Compress ® QuickCompress ® – AAAC & ACAR Quick Compress Terminal for AAAC and ACAR Conductor, Straight, TS Series (cont.) CATALOG NUMBER CONDUCTOR DIE SIZE TOTAL WEIGHT DIMENSION PAD SIZE CODE WORD SIZE DIAMETER A L KCMIL IN LBS KG IN MM IN MM TS07 — 281 4 0 609 07CD 0 5 0 20 0 3 8 9 0 229 B TS07 Butte 312 8 0 642 07CD 0 5 0 20 0 3 8 9 0 229 B TS08 — 355 1 0 684 08CD 0 6 0 28 0 4 10 9 6 244 B TS08 Canton 394 5 0 721 08CD 0 6 0 28 0 4 10 9 6 244 B TS08 — 419 6 0 743 08CD 0 6 0 28 0 4 10 9 6 244 B TS09 Cairo 465 4 0 783 09CD 0 8 0 38 0 4 11 10 0 254 B TS09 — 503 6 0 814 09CD 0 8 0 38 0 4 11 10 0 254 B TS10 Darien 559 5 0 858 10CD 1 1 0 50 0 5 12 10 6 269 B TS10 — 587 2 0 879 10CD 1 1 0 50 0 5 12 10 6 269 B TS10 — 634 9 0 914 10CD 1 1 0 50 0 5 12 10 6 269 B TS10 — 649 5 0 928 10CD 1 1 0 50 0 5 12 10 6 269 B TS10 Elgin 652 4 0 927 10CD 1 1 0 50 0 5 12 10 6 269 B TS10 — 657 3 0 930 10CD 1 1 0 50 0 5 12 10 6 269 B TS11 Flint 740 8 0 991 11CD 1 5 0 68 0 4 9 11 7 297 D TS12 — 853 7 1 063 12CD 1 8 0 82 0 4 11 12 1 307 D TS12 Greeley 927 2 1 108 12CD 1 8 0 82 0 4 11 12 1 307 D TS13 — 1024 5 1 165 13CD 2 1 0 95 0 5 13 12 8 325 D TS13 — 1080 6 1 196 13CD 2 1 0 95 0 5 13 12 8 325 D TS13 — 1108 6 1 212 13CD 2 1 0 95 0 5 13 12 8 325 D TS14 — 1172 3 1 246 14CD 2 7 1 22 0 6 16 13 8 351 D TS16 — 1534 0 1 427 16CD 3 8 1 72 0 7 17 14 6 371 D TS16 — 1700 0 1 502 16CD 3 8 1 72 0 7 17 14 6 371 D TS19 — 2303 5 1 750 19CD 6 5 2 95 0 9 22 17 5 445 E TS19 — 2338 0 1 762 19CD 6 5 2 95 0 9 22 17 5 445 E TS20 — 2493 0 1 821 20CD 7 3 3 31 0 9 22 17 9 455 E 243 Quick Compress ® QuickCompress ® – AAAC & ACAR © 2003, AFL, all rights reserved. PP-3-00758, Revision 3, 3.9.2021 Specifications are subject to change without notice. AFLglobal.com | 800.866.7385 The TF Series 15º Terminal Connector is designed for fast and easy installation By using a high strength alloy, the compression length has been shortened for less compression bites The termi - nal connector is pre-filled, eliminating an installation step When used with the Quick Compress dead end, the TF Series connectors can be bolted in either straight or 30º position All TF Series connectors are designed for limited tension use, maintaining a minimum of 40% of the ASTM rated strength of the conductor The end tapers of all compression accessories are supplied with a High Voltage finish for die size sections 12CD and above The square edges of bolted pads of the compression accessories could cause Corona Pads with edges and corners rounded can be supplied by adding the catalog suffix 'EHV' Ordering Instructions Step 1: Catalog Number Determine the catalog number based on the conductor being used Step 2: Extra High Voltage Finish For Extra High Voltage Finish, use 'EHV' ( ≥ 345 kV) For Standard Finish, leave blank ( < 345 kV) Step 3: Assemble Catalog Number. Example: A 15º terminal for 927 7 Greeley with an EHV finish, the complete catalog number is: TF12EHV Catalog Number EHV Finish + Notes: 1 Pad Dimensions are on page 257 2 Installation Instructions for Terminals are on page 272 3 Bolts, nuts and washers are supplied with TF Series Terminal Connectors 4 For more information on die selection and ordering instructions, see Tools and Equipment tab in this catalog Quick Compress Terminal for AAAC and ACAR Conductor, 15º, TF Series © 2003, AFL, all rights reserved. PP-3-00758, Revision 3, 3.9.2021 Specifications are subject to change without notice. AFLglobal.com | 800.866.7385 244 Quick Compress ® QuickCompress ® – AAAC & ACAR Quick Compress Terminal for AAAC and ACAR Conductor, 15º, TF Series (cont.) CATALOG NUMBER CONDUCTOR DIE SIZE TOTAL WEIGHT DIMENSIONS PAD SIZE CODE WORD SIZE DIAMETER A L KCMIL IN LBS KG IN MM IN MM TF07 — 281 4 0 609 07CD 0 5 0 24 0 3 8 7 8 196 B TF07 Butte 312 8 0 642 07CD 0 5 0 24 0 3 8 7 8 196 B TF08 — 355 1 0 684 08CD 0 7 0 31 0 4 10 8 3 211 B TF08 Canton 394 5 0 721 08CD 0 7 0 31 0 4 10 8 3 211 B TF08 — 419 6 0 743 08CD 0 7 0 31 0 4 10 8 3 211 B TF09 Cairo 465 4 0 783 09CD 0 9 0 40 0 4 11 8 9 226 B TF09 — 503 6 0 814 09CD 0 9 0 40 0 4 11 8 9 226 B TF10 Darien 559 5 0 858 10CD 1 1 0 50 0 5 12 9 4 239 B TF10 — 587 2 0 879 10CD 1 1 0 50 0 5 12 9 4 239 B TF10 — 634 9 0 914 10CD 1 1 0 50 0 5 12 9 4 239 B TF10 — 649 5 0 928 10CD 1 1 0 50 0 5 12 9 4 239 B TF10 Elgin 652 4 0 927 10CD 1 1 0 50 0 5 12 9 4 239 B TF10 — 657 3 0 930 10CD 1 1 0 50 0 5 12 9 4 239 B TF11 Flint 740 8 0 991 11CD 1 5 0 68 0 4 9 10 4 264 D TF12 — 853 7 1 063 12CD 1 9 0 86 0 4 11 11 0 279 D TF12 Greeley 927 2 1 108 12CD 1 9 0 86 0 4 11 11 0 279 D TF13 — 1024 5 1 165 13CD 2 2 1 00 0 5 13 11 2 284 D TF13 — 1080 6 1 196 13CD 2 2 1 00 0 5 13 11 2 284 D TF13 — 1108 6 1 212 13CD 2 2 1 00 0 5 13 11 2 284 D TF14 — 1172 3 1 246 14CD 2 8 1 27 0 6 16 12 0 305 D TF16 — 1534 0 1 427 16CD 3 7 1 69 0 7 17 13 3 338 D TF16 — 1700 0 1 502 16CD 3 7 1 69 0 7 17 13 3 338 D TF19 — 2303 5 1 750 19CD 6 3 2 86 0 9 22 15 7 399 E TF19 — 2338 0 1 762 19CD 6 3 2 86 0 9 22 15 7 399 E TF20 — 2493 0 1 821 20CD 6 8 3 08 0 9 22 16 0 406 E 245 Quick Compress ® QuickCompress ® – AAAC & ACAR © 2003, AFL, all rights reserved. PP-3-00758, Revision 3, 3.9.2021 Specifications are subject to change without notice. AFLglobal.com | 800.866.7385 The T45 Series 45º Terminal Connector is designed for fast and easy installation By using a high strength alloy, the compression length has been shortened for less compression bites The termi - nal connector is pre-filled, eliminating an installation step All T45 Series connectors are designed for limited tension use, maintaining a minimum of 40% of the ASTM rated strength of the conductor The end tapers of all compression accessories are supplied with a High Voltage finish for die size sections 12CD and above The square edges of bolted pads of the compression accessories could cause Corona Pads with edges and corners rounded can be supplied by adding the catalog suffix 'EHV' Ordering Instructions Step 1: Catalog Number Determine the catalog number based on the conductor being used Step 2: Extra High Voltage Finish For Extra High Voltage Finish, use 'EHV' ( ≥ 345 kV) For Standard Finish, leave blank ( < 345 kV) Step 3: Assemble Catalog Number. Example: A 45º terminal for 927 7 Greeley with an EHV finish, the complete catalog number is: T4512EHV Catalog Number EHV Finish + Notes: 1 Pad Dimensions are on page 257 2 Installation Instructions for Terminals are on page 272 3 Bolts, nuts and washers are not supplied with T45 Series Terminal Connectors 4 For more information on die selection and ordering instructions, see Tools and Equipment tab in this catalog Quick Compress Terminal for AAAC and ACAR Conductor, 45º, T45 Series © 2003, AFL, all rights reserved. PP-3-00758, Revision 3, 3.9.2021 Specifications are subject to change without notice. AFLglobal.com | 800.866.7385 246 Quick Compress ® QuickCompress ® – AAAC & ACAR Quick Compress Terminal for AAAC and ACAR Conductor, 45º, T45 Series (cont.) CATALOG NUMBER CONDUCTOR DIE SIZE TOTAL WEIGHT DIMENSIONS PAD SIZE CODE WORD SIZE DIAMETER A L KCMIL IN LBS KG IN MM IN MM T4507 — 281 4 0 609 07CD 0 4 0 19 0 3 8 7 3 185 B T4507 Butte 312 8 0 642 07CD 0 4 0 19 0 3 8 7 3 185 B T4508 — 355 1 0 684 08CD 0 6 0 25 0 4 10 7 8 198 B T4508 Canton 394 5 0 721 08CD 0 6 0 25 0 4 10 7 8 198 B T4508 — 419 6 0 743 08CD 0 6 0 25 0 4 10 7 8 198 B T4509 Cairo 465 4 0 783 09CD 0 8 0 34 0 4 11 8 2 208 B T4509 — 503 6 0 814 09CD 0 8 0 34 0 4 11 8 2 208 B T4510 Darien 559 5 0 858 10CD 1 0 0 45 0 5 12 8 6 218 B T4510 — 587 2 0 879 10CD 1 0 0 45 0 5 12 8 6 218 B T4510 — 634 9 0 914 10CD 1 0 0 45 0 5 12 8 6 218 B T4510 — 649 5 0 928 10CD 1 0 0 45 0 5 12 8 6 218 B T4510 Elgin 652 4 0 927 10CD 1 0 0 45 0 5 12 8 6 218 B T4510 — 657 3 0 930 10CD 1 0 0 45 0 5 12 8 6 218 B T4511 Flint 740 8 0 991 11CD 1 3 0 59 0 4 9 9 4 239 D T4512 — 853 7 1 063 12CD 1 6 0 73 0 4 11 9 7 246 D T4512 Greeley 927 2 1 108 12CD 1 6 0 73 0 4 11 9 7 246 D T4513 — 1024 5 1 165 13CD 2 0 0 91 0 5 13 10 2 259 D T4513 — 1080 6 1 196 13CD 2 0 0 91 0 5 13 10 2 259 D T4513 — 1108 6 1 212 13CD 2 0 0 91 0 5 13 10 2 259 D T4514 — 1172 3 1 246 14CD 2 3 1 04 0 6 16 10 6 269 D T4516 — 1534 0 1 427 16CD 3 4 1 54 0 7 17 11 0 279 D T4516 — 1700 0 1 502 16CD 3 4 1 54 0 7 17 11 0 279 D T4519 — 2303 5 1 750 19CD 5 7 2 59 0 9 22 13 7 348 E T4519 — 2338 0 1 762 19CD 5 7 2 59 0 9 22 13 7 348 E T4520 — 2493 0 1 821 20CD 6 5 2 95 0 9 22 14 2 361 E 247 Quick Compress ® QuickCompress ® – AAAC & ACAR © 2003, AFL, all rights reserved. PP-3-00758, Revision 3, 3.9.2021 Specifications are subject to change without notice. AFLglobal.com | 800.866.7385 The TN Series 90º Terminal Connector is designed for fast and easy installation By using a high strength alloy, the compression length has been shortened for less compression bites The termi - nal connector is pre-filled, eliminating an installation step All TN Series connectors are designed for limited tension use, maintaining a minimum of 40% of the ASTM rated strength of the conductor The end tapers of all compression accessories are supplied with a High Voltage finish for die size sections 12CD and above The square edges of bolted pads of the compression accessories could cause Corona Pads with edges and corners rounded can be supplied by adding the catalog suffix 'EHV' Ordering Instructions Step 1: Catalog Number Determine the catalog number based on the conductor being used Step 2: Extra High Voltage Finish For Extra High Voltage Finish, use 'EHV' ( ≥ 345 kV) For Standard Finish, leave blank ( < 345 kV) Step 3: Assemble Catalog Number. Example: A 90º terminal for 927 7 Greeley with an EHV finish, the complete catalog number is: TN12EHV Catalog Number EHV Finish + Notes: 1 Pad Dimensions are on page 257 2 Installation Instructions for Terminals are on page 272 3 Bolts, nuts and washers are not supplied with TN Series Terminal Connectors 4 For more information on die selection and ordering instructions, see Tools and Equipment tab in this catalog Quick Compress Terminal for AAAC and ACAR Conductor, 90º, TN Series © 2003, AFL, all rights reserved. PP-3-00758, Revision 3, 3.9.2021 Specifications are subject to change without notice. AFLglobal.com | 800.866.7385 248 Quick Compress ® QuickCompress ® – AAAC & ACAR Quick Compress Terminal for AAAC and ACAR Conductor, 90º, TN Series (cont.) CATALOG NUMBER CONDUCTOR DIE SIZE TOTAL WEIGHT DIMENSIONS PAD SIZE CODE WORD SIZE DIAMETER A L KCMIL IN LBS KG IN MM IN MM TN07 — 281 4 0 609 07CD 0 5 0 20 0 3 8 5 2 132 B TN07 Butte 312 8 0 642 07CD 0 5 0 20 0 3 8 5 2 132 B TN08 — 355 1 0 684 08CD 0 6 0 29 0 4 10 5 7 145 B TN08 Canton 394 5 0 721 08CD 0 6 0 29 0 4 10 5 7 145 B TN08 — 419 6 0 743 08CD 0 6 0 29 0 4 10 5 7 145 B TN09 Cairo 465 4 0 783 09CD 0 8 0 38 0 4 11 6 2 157 B TN09 — 503 6 0 814 09CD 0 8 0 38 0 4 11 6 2 157 B TN10 Darien 559 5 0 858 10CD 1 1 0 50 0 5 12 6 7 170 B TN10 — 587 2 0 879 10CD 1 1 0 50 0 5 12 6 7 170 B TN10 — 634 9 0 914 10CD 1 1 0 50 0 5 12 6 7 170 B TN10 — 649 5 0 928 10CD 1 1 0 50 0 5 12 6 7 170 B TN10 Elgin 652 4 0 927 10CD 1 1 0 50 0 5 12 6 7 170 B TN10 — 657 3 0 930 10CD 1 1 0 50 0 5 12 6 7 170 B TN11 Flint 740 8 0 991 11CD 1 4 0 64 0 4 9 7 5 191 D TN12 — 853 7 1 063 12CD 1 8 0 82 0 4 11 7 9 202 D TN12 Greeley 927 2 1 108 12CD 1 8 0 82 0 4 11 7 9 202 D TN13 — 1024 5 1 165 13CD 2 2 1 00 0 5 13 8 5 216 D TN13 — 1080 6 1 196 13CD 2 2 1 00 0 5 13 8 5 216 D TN13 — 1108 6 1 212 13CD 2 2 1 00 0 5 13 8 5 216 D TN14 — 1172 3 1 246 14CD 2 6 1 18 0 6 16 9 2 233 D TN16 — 1534 0 1 427 16CD 3 7 1 68 0 7 17 10 2 259 D TN16 — 1700 0 1 502 16CD 3 7 1 68 0 7 17 10 2 259 D TN19 — 2303 5 1 750 19CD 6 1 2 77 0 9 22 11 9 303 E TN19 — 2338 0 1 762 19CD 6 1 2 77 0 9 22 11 9 303 E TN20 — 2493 0 1 821 20CD 6 9 3 13 0 9 22 12 6 321 E
