Tee connector is designed to make a tee connection in bus construction. Connector can be used on Schedule 40 and Schedule 80 pipe.
ab1cb471c90847f3b11358cd68bb682e
328 230 kV Aluminum Bolted Tee & V ee Connectors © 2011, AFL, all rights reserved. PP-3-00239, Revision 1, 8.21.17 Specifications are subject to change without notice. www.AFLglobal.com or 800-890-8878 230 kV Aluminum Bolted Tee & Vee Connectors Tee connector is designed to make a tee connection in bus construction. Connector can be used on Schedule 40 and Schedule 80 pipe. Four clamp bolts on each conductor ensures positive electrical contact. Material Aluminum Alloy Hardware Yellow anodized aluminum bolts, nuts, and lockwashers. TYPE BAP-AA Tee Connector Notes Contact surfaces can be precoated by adding suffix -LP. B L Ordering Information CATALOG NUMBER SPS DIMENSIONS IN INCHES BOLT SIZE MAIN TAP B L BAP75-75-AA 3/4 3/4 2 3/4 5 13/16 1/2 BAP100-50-AA 1 1/2 2 3/4 6 1/16 1/2 BAP100-75-AA 1 3/4 2 3/4 6 1/16 1/2 BAP100-100-AA 1 1 2 3/4 6 1/16 1/2 BAP100-150-AA 1 1 1/2 2 3/4 6 5/16 1/2 BAP100-200-AA 1 2 2 3/4 6 9/16 1/2 BAP100-250-AA 1 2 1/2 2 3/4 6 9/16 1/2 BAP125-75-AA 1 1/4 3/4 3 6 13/32 1/2 BAP125-100-AA 1 1/4 1 3 6 13/32 1/2 BAP125-125-AA 1 1/4 1 1/4 3 6 21/32 1/2 BAP150-75-AA 1 1/2 3/4 3 6 21/32 1/2 BAP150-100-AA 1 1/2 1 3 6 21/32 1/2 BAP150-125-AA 1 1/2 1 1/4 3 6 29/32 1/2 BAP150-150-AA 1 1/2 1 1/2 3 6 29/32 1/2
329 230 kV Aluminum Bolted Tee & V ee Connectors © 2011, AFL, all rights reserved. PP-3-00239, Revision 1, 8.21.17 Specifications are subject to change without notice. 230 kV Aluminum Bolted Tee & Vee Connectors www.AFLglobal.com or 800-890-8878 Ordering Information CATALOG NUMBER SPS DIMENSIONS IN INCHES BOLT SIZE MAIN TAP B L BAP150-200-AA 1 1/2 2 3 7 5/32 1/2 BAP150-250-AA 1 1/2 2 1/2 3 7 5/32 1/2 BAP150-300-AA 1 1/2 3 3 7 3/8 1/2 BAP200-75-AA 2 3/4 3 1/4 7 1/8 1/2 BAP200-100-AA 2 1 3 1/4 7 1/8 1/2 BAP200-125-AA 2 1 1/4 3 1/4 7 3/8 1/2 BAP200-150-AA 2 1 1/2 3 1/4 7 3/8 1/2 BAP200-200-AA 2 2 3 1/4 7 5/8 1/2 BAP200-250-AA 2 2 1/2 3 1/4 7 5/8 1/2 BAP200-300-AA 2 3 3 1/4 7 7/8 1/2 BAP200-350-AA 2 3 1/2 3 1/4 8 1/4 1/2 and 5/8 BAP200-62R-S-AA 2 5/8R 3 1/4 6 1/2 1/2 BAP250-75-AA 2 1/2 3/4 3 1/4 7 5/8 1/2 BAP250-100-AA 2 1/2 1 3 1/4 7 5/8 1/2 BAP250-125-AA 2 1/2 1 1/4 3 1/4 7 7/8 1/2 BAP250-150-AA 2 1/2 1 1/2 3 1/4 7 7/8 1/2 BAP250-200-AA 2 1/2 2 3 1/4 8 1/8 1/2 BAP250-250-AA 2 1/2 2 1/2 3 1/4 8 1/8 1/2 BAP250-300-AA 2 1/2 3 3 1/4 8 3/8 1/2 BAP250-350-AA 2 1/2 3 1/2 3 1/4 8 1/4 1/2 BAP300-75-AA 3 3/4 3 8 1/4 1/2 BAP300-100-AA 3 1 3 8 1/2 1/2 BAP300-125-AA 3 1 1/4 3 8 1/2 1/2 BAP300-150-AA 3 1 1/2 3 1/2 8 3/4 1/2 BAP300-200-AA 3 2 3 1/2 8 3/4 1/2 BAP300-250-AA 3 2 1/2 3 1/2 8 3/4 1/2 BAP300-300-AA 3 3 3 3/4 8 3/4 5/8 BAP350-100-AA 3 1/2 1 3 1/2 8 3/4 1/2 BAP350-125-AA 3 1/2 1 1/4 3 1/2 9 1/2 BAP350-150-AA 3 1/2 1 1/2 3 1/2 9 1/2 BAP350-200-AA 3 1/2 2 3 1/2 9 1/4 1/2 BAP350-250-AA 3 1/2 2 1/2 3 1/2 9 1/4 5/8 and 1/2 BAP350-300-AA 3 1/2 3 3 3/4 10 5/8 BAP350-350-AA 3 1/2 3 1/2 3 3/4 10 5/8 BAP400-100-AA 4 1 3 1/4 9 1/4 1/2 BAP400-125-AA 4 1 1/4 3 1/4 9 1/2 1/2 BAP400-150-AA 4 1 1/2 3 1/4 9 1/2 1/2 BAP400-200-AA 4 2 3 1/4 9 3/4 1/2 BAP400-250-AA 4 2 1/2 3 1/4 9 3/4 1/2 BAP400-300-AA 4 3 3 3/4 10 1/2 5/8 BAP400-350-AA 4 3 1/2 3 3/4 10 1/2 5/8 BAP400-400-AA 4 4 3 3/4 10 5/8 5/8 BAP500-150-AA 5 1 1/2 3 3/4 10 15/16 5/8 and 1/2 BAP500-250-AA 5 2 1/2 3 3/4 10 15/32 1/2 BAP500-300-AA 5 3 3 3/4 11 3/4 5/8 BAP500-500-AA 5 5 7 15 5/8 BAP600-300-AA 6 3 3 3/4 12 3/4 5/8 BAP600-600-AA 6 6 8 17 5/8 BAP125-118R-AA 1 1/4 30MM 3 6 13/32 1/2 BAP-500-393R-AA 5 100MM 3 3/4 11 3/4 5/8 TYPE BAP-AA Tee Connector
332 230 kV Aluminum Bolted Tee & V ee Connectors © 2011, AFL, all rights reserved. PP-3-00252, Revision 3, 12.18.18 Specifications are subject to change without notice. www.AFLglobal.com or 800-890-8878 230 kV Aluminum Bolted Tee & Vee Connectors An aluminum tee connector designed for maximum efficiency and reliability. Connector can be used with Schedule 40 and Schedule 80 pipe. Material Aluminum Alloy Hardware Yellow anodized aluminum bolts, nuts, and lockwashers. TYPE BP-AA, BPA-75-AA, BPA-80-AA Standard, 75 Degree and 80 Degree Tee Connector B BP-AA A A 75º 80º BPA-75-AA BPA-80-AA BP-AA BPA-AA B
333 230 kV Aluminum Bolted Tee & V ee Connectors © 2011, AFL, all rights reserved. PP-3-00252, Revision 3, 12.18.18 Specifications are subject to change without notice. 230 kV Aluminum Bolted Tee & Vee Connectors www.AFLglobal.com or 800-890-8878 Ordering Information CATALOG NUMBER SPS DIMENSIONS IN INCHES BOLT SIZE STANDARD 75 DEGREES 80 DEGREES RUN TAP A B BP100-75-AA BPA100-75-75-AA BPA100-75-80-AA 1 3/4 2-3/4 2-3/4 1/2 BP100-100-AA BPA100-100-75-AA BPA100-100-80-AA 1 1 2-3/4 2-3/4 1/2 BP125-75-AA BPA125-75-75-AA BPA125-75-80-AA 1-1/4 3/4 3 2-3/4 1/2 BP125-100-AA BPA125-100-75-AA BPA125-100-80-AA 1-1/4 1 3 2-3/4 1/2 BP125-125-AA BPA125-125-75-AA BPA125-125-80-AA 1-1/4 1-1/4 3 3 1/2 BP150-100-AA BPA150-100-75-AA BPA150-100-80-AA 1-1/2 1 3 2-3/4 1/2 BP150-125-AA BPA150-125-75-AA BPA150-125-80-AA 1-1/2 1-1/4 3 3 1/2 BP150-150-AA BPA150-150-75-AA BPA150-150-80-AA 1-1/2 1-1/2 3 3 1/2 BP200-100-AA BPA200-100-75-AA BPA200-100-80-AA 2 1 3-1/4 2-3/4 1/2 BP200-125-AA BPA200-125-75-AA BPA200-125-80-AA 2 1-1/4 3-1/4 3 1/2 BP200-150-AA BPA200-150-75-AA BPA200-150-80-AA 2 1-1/2 3-1/4 3 1/2 BP200-200-AA BPA200-200-75-AA BPA200-200-80-AA 2 2 3-1/4 3-1/4 1/2 BP200-250-AA BPA200-250-75-AA BPA200-250-80-AA 2 2-1/2 3-1/4 3-1/4 1/2 BP250-75-AA BPA250-75-75-AA BPA250-75-80-AA 2-1/2 3/4 3-1/4 2-3/4 1/2 BP250-100-AA BPA250-100-75-AA BPA250-100-80-AA 2-1/2 1 3-1/4 2-3/4 1/2 BP250-125-AA BPA250-125-75-AA BPA250-125-80-AA 2-1/2 1-1/4 3-1/4 3 1/2 BP250-150-AA BPA250-150-75-AA BPA250-150-80-AA 2-1/2 1-1/2 3-1/4 3 1/2 BP250-200-AA BPA250-200-75-AA BPA250-200-80-AA 2-1/2 2 3-1/4 3-1/4 1/2 BP250-250-AA BPA250-250-75-AA BPA250-250-80-AA 2-1/2 2-1/2 3-1/4 3-1/4 1/2 BP300-100-AA BPA300-100-75-AA BPA300-100-80-AA 3 1 3-1/4 2-3/4 1/2 BP300-125-AA BPA300-125-75-AA BPA300-125-80-AA 3 1-1/4 3-1/4 3 1/2 BP300-150-AA BPA300-150-75-AA BPA300-150-80-AA 3 1-1/2 3-1/4 3 1/2 BP300-200-AA BPA300-200-75-AA BPA300-200-80-AA 3 2 3-1/4 3-1/4 1/2 BP300-250-AA BPA300-250-75-AA BPA300-250-80-AA 3 2-1/2 3-1/4 3-1/4 1/2 BP300-300-AA BPA300-300-75-AA BPA300-300-80-AA 3 3 3-3/4 3-3/4 5/8 BP350-100-AA BPA350-100-75-AA BPA350-100-80-AA 3-1/2 1 3-1/4 2-3/4 1/2 BP350-125-AA BPA350-125-75-AA BPA350-125-80-AA 3-1/2 1-1/4 3-1/4 3 1/2 BP350-150-AA BPA350-150-75-AA BPA350-150-80-AA 3-1/2 1-1/2 3-1/4 3 1/2 BP350-200-AA BPA350-200-75-AA BPA350-200-80-AA 3-1/2 2 3-1/4 3-1/4 1/2 BP350-250-AA BPA350-250-75-AA BPA350-250-80-AA 3-1/2 2-1/2 3-1/4 3-1/4 1/2 BP350-300-AA BPA350-300-75-AA BPA350-300-80-AA 3-1/2 3 3-3/4 3-3/4 5/8 BP350-350-AA BPA350-350-75-AA BPA350-350-80-AA 3-1/2 3-1/2 3-3/4 3-3/4 5/8 BP400-125-AA BPA400-125-75-AA BPA400-125-80-AA 4 1-1/4 3-1/4 3 1/2 BP400-150-AA BPA400-150-75-AA BPA400-150-80-AA 4 1-1/2 3-1/4 3 1/2 BP400-200-AA BPA400-200-75-AA BPA400-200-80-AA 4 2 3-1/4 3-1/4 1/2 BP400-250-AA BPA400-250-75-AA BPA400-250-80-AA 4 2-1/2 3-1/4 3-1/4 1/2 BP400-300-AA BPA400-300-75-AA BPA400-300-80-AA 4 3 3-3/4 3-3/4 5/8 BP400-350-AA BPA400-350-75-AA BPA400-350-80-AA 4 3-1/2 3-3/4 3-3/4 5/8 BP400-400-AA BPA400-400-75-AA BPA400-400-80-AA 4 4 3-3/4 3-3/4 5/8 BP500-150-AA BPA500-150-75-AA BPA500-150-80-AA 5 1-1/2 3-1/2 3 1/2 BP500-200-AA BPA500-200-75-AA BPA500-200-80-AA 5 2 3-1/2 3-1/4 1/2 BP500-250-AA BPA500-250-75-AA BPA500-250-80-AA 5 2-1/2 3-1/2 3-1/4 1/2 BP500-300-AA BPA500-300-75-AA BPA500-300-80-AA 5 3 3-3/4 3-3/4 5/8 BP500-350-AA BPA500-350-75-AA BPA500-350-80-AA 5 3-1/2 4 3-3/4 5/8 BP500-400-AA BPA500-400-75-AA BPA500-400-80-AA 5 4 4 3-3/4 5/8 BP500-500-AA BPA500-500-75-AA BPA500-500-80-AA 5 5 4 4 5/8 BP600-250-AA BPA600-250-75-AA BPA600-250-80-AA 6 2-1/2 3-1/2 3-1/4 1/2 BP600-300-AA BPA600-300-75-AA BPA600-300-80-AA 6 3 4 3-3/4 5/8 BP600-350-AA BPA600-350-75-AA BPA600-350-80-AA 6 3-1/2 4 3-3/4 5/8 BP600-400-AA BPA600-400-75-AA BPA600-400-80-AA 6 4 4 3-3/4 5/8 BP600-500-AA BPA600-500-75-AA BPA600-500-80-AA 6 5 4 4 5/8 BP600-600-AA BPA600-600-75-AA BPA600-600-80-AA 6 6 4 4 5/8 TYPE BP-AA, BPA-75-AA, BPA-80-AA Standard, 75 Degree, and 80 Degree Tee Connector
Features:
- Aluminum alloy
- Anodized aluminum hardware
- External bus pipe fit for SCH 40 and SCH 80 bus pipe
- Meets the standards of NEMA CC1
Applications:
- Rated for 230 kV
- Substation
- Aluminum bus pipe
Tee connector is designed to make a tee connection in bus construction. Connector can be used on Schedule 40 and Schedule 80 pipe.
230 kV Aluminum Compression Couplers,230 kV Aluminum Compression Tee Connectors,230 kV Aluminum Compression Tee Terminal Connectors,230 kV Aluminum Compression Terminal Connectors,230 kV Aluminum Welded Bus Pipe Couplers,230 kV Aluminum Welded Bus Pipe Elbows,230 kV Aluminum Welded Bus Pipe Supports,230 kV Aluminum Welded Bus Pipe Tee and Vee Connectors,230 kV Aluminum Welded Bus Pipe Terminal Connectors,230 kV Aluminum Welded Bus Pipe to Cable Couplers,230 kV Aluminum Welded Bus Pipe to Cable Tee,230 kV Aluminum Welded Cable Terminal,230 kV Aluminum Welded End Plugs,230 kV Aluminum Welded Grounding Rod,230 kV Aluminum Welded Pipe Taps
233
230 kV Aluminum Bolted Bus Pipe Tee Connectors
Close
230 kV Aluminum Bolted Bus Pipe Tee Connectors
Features:
- Aluminum alloy
- Anodized aluminum hardware
- External bus pipe fit for SCH 40 and SCH 80 bus pipe
- Meets the standards of NEMA CC1
Applications:
- Rated for 230 kV
- Substation
- Aluminum bus pipe
PRODUCT DESCRIPTION
Tee connector is designed to make a tee connection in bus construction. Connector can be used on Schedule 40 and Schedule 80 pipe.
