Conectores de transformador atornillados de bronce
0404a973ff1249859851295871ad551c
156 Bronze Grounding Connectors and Everdur Hardware © 2011, AFL, all rights reserved. PP-3-00386, Revision 0, 3.8.11 Specifications are subject to change without notice. www.AFLglobal.com or 800-890-8878 Bronze Grounding Connectors and Everdur Hardware Ordering Information CATALOG NUMBER DIMENSIONS IN INCHES MTRC MTR2C MTR3C A B D MTRC-38 MTR2C-38 MTR3C-38 1 3/8 2 3/8 MTRC-56 MTR2C-56 MTR3C-56 1 1/2 2 1/4 9/16 MTRC-75 MTR2C-75 MTR3C-75 1 9/16 2 3/4 3/4 MTRC-88 MTR2C-88 MTR3C-88 1 5/8 3 1/2 7/8 MTRC-112 MTR2C-112 MTR3C-112 1 3/4 4 1 1/8 A multiple tie transformer connector which provides a convenient means of connecting a number of cables to a single transformer terminal. Allows maximum conductor sizes to be run directly to the transformer, thereby minimizing voltage drop. Material Tin plated copper Hardware • MTR2C: Four hole NEMA standard drilled contact. • MTR3C: Six hole NEMA standard drilled contact. Type MTRC, MTR2C, and MTR3C Multiple Tie Transformer Connector 1 3/4 D Ø 9/16 5/8 A 3/4 3/4 A 1 3/4 1 3/4 5/8 B Ø 9/16 B MTRC D MTR2C MTR3C D B Ø 9/16 5/8 1 3/4 3/4 1 3/4 1 3/4 A 1/4
157 Bronze Grounding Connectors and Everdur Hardware © 2011, AFL, all rights reserved. PP-3-00423, Revision 0, 3.8.11 Specifications are subject to change without notice. Bronze Grounding Connectors and Everdur Hardware www.AFLglobal.com or 800-890-8878 A cast type multiple tee connector for securing a number of cables to a single transformer terminal. Each cable clamping position is designed to receive a wide range of conductor sizes. Installation of each cable is simply accomplished by insertion of cable into eyebolt member and tightening nut with a single wrench. Body is of high conductivity copper alloy and eyebolt elements are of high strength bronze with silicon bronze nuts and lockwashers. TYPE Q2TE, Q3TE, Q4TE Cast Copper multiple tee connector for securing a number of cables to a single transformer terminal. Q2TE D W C L Q2TE Q3TE Q4TE Material Copper Alloy Hardware Everdur nut and lockwashers.
158 Bronze Grounding Connectors and Everdur Hardware © 2011, AFL, all rights reserved. PP-3-00423, Revision 0, 3.8.11 Specifications are subject to change without notice. www.AFLglobal.com or 800-890-8878 Bronze Grounding Connectors and Everdur Hardware TYPE Q2TE, Q3TE, Q4TE Cast Copper multiple tee connector for securing a number of cables to a single transformer terminal. Ordering Information CATALOG NUMBER CABLE RANGE DIMENSIONS IN INCHES C D L W Q2TE-13 8 Solid- 2/0 Stranded 2 3/8 3 5/8 2 1/8 Q3TE-13 8 Solid- 2/0 Stranded 2 3/8 3 5/8 3 1/4 Q4TE-13 8 Solid- 2/0 Stranded 2 3/8 3 5/8 3 3/4 Q2TE-25 6 Solid- 250 kcmil 2 1/4 9/16 4 1/8 2 5/8 Q3TE-25 6 Solid- 250 kcmil 2 1/4 9/16 4 1/8 3 7/8 Q4TE-25 6 Solid- 250 kcmil 2 1/4 9/16 4 1/8 4 1/2 Q2TE-35 2 Solid- 350 kcmil 2 3/4 3/4 4 1/2 2 3/4 Q3TE-35 2 Solid- 350 kcmil 2 3/4 3/4 4 1/2 4 1/8 Q4TE-35 2 Solid- 350 kcmil 2 3/4 3/4 4 1/2 4 7/8 Q2TE-50 1/0 Solid- 500 kcmil 3 1/2 7/8 5 3/4 3 1/8 Q3TE-50 1/0 Solid- 500 kcmil 3 1/2 7/8 5 3/4 4 7/8 Q4TE-50 1/0 Solid- 500 kcmil 3 1/2 7/8 5 3/4 5 7/8 Q2TE-100 2/0 Solid- 1000 kcmil 4 1 1/8 6 3/8 4 Q3TE-100 2/0 Solid- 1000 kcmil 4 1 1/8 6 3/8 5 7/8 Q4TE-100 2/0 Solid- 1000 kcmil 4 1 1/8 6 3/8 7 5/8
159 Bronze Grnd Connectors & Everdur Hardware © 2011, AFL, all rights reserved. PP-3-00424, Revision 1, 1.5.2023 Specifications are subject to change without notice. AFLglobal.com | 800.890.8878 Bronze Grounding Connectors and Everdur Hardware A cast type multiple tee connector for securing a number of cables to a single transformer terminal. Each cable clamping position is designed to receive a wide range of conductor sizes. Installation of each cable is simply accomplished by insertion of cable into eyebolt member and tightening nut with a single wrench. Body is of high conductivity copper alloy and eyebolt elements are of high strength bronze with silicon bronze nuts and lockwashers. Material Copper Alloy Hardware Everdur nut and lockwashers. TYPE Q2TS, Q3TS, Q4TS Cast Copper multiple tee connector for securing a number of cables to a single transformer terminal. Q2TS D B C L Q2TS Q3TS Q4TS
© 2011, AFL, all rights reserved. PP-3-00424, Revision 1, 1.5.2023 Specifications are subject to change without notice. AFLglobal.com | 800.890.8878 160 Bronze Grounding Connectors and Everdur Hardware Bronze Grnd Connectors & Everdur Hardware Ordering Information CATALOG NUMBER CABLE RANGE DIMENSIONS IN INCHES B C D L Q2TS-13 8 Solid- 2/0 Stranded 1 1/2 2 3/8 4 3/8 Q3TS-13 8 Solid- 2/0 Stranded 1 1/2 2 3/8 5 1/4 Q4TS-13 8 Solid- 2/0 Stranded 1 1/2 2 3/8 6 1/8 Q2TS-25 6 Solid- 250 kcmil 1 5/8 2 1/4 9/16 5 Q3TS-25 6 Solid- 250 kcmil 1 5/8 2 1/4 9/16 6 3/8 Q4TS-25 6 Solid- 250 kcmil 1 5/8 2 1/4 9/16 7 1/8 Q2TS-35 2 Solid- 350 kcmil 1 11/16 2 3/4 3/4 5 Q3TS-35 2 Solid- 350 kcmil 1 11/16 2 3/4 3/4 6 3/8 Q4TS-35 2 Solid- 350 kcmil 1 11/16 2 3/4 3/4 7 1/8 Q2TS-50 1/0 Solid- 500 kcmil 1 3/4 4 7/8 7 1/4 Q3TS-50 1/0 Solid- 500 kcmil 2 1/8 3 1/2 7/8 8 1/2 Q4TS-50 1/0 Solid- 500 kcmil 2 1/8 3 1/2 7/8 9 1/8 Q2TS-100 2/0 Solid- 1000 kcmil 2 1/4 4 1 1/8 8 1/8 Q3TS-100 2/0 Solid- 1000 kcmil 2 1/4 4 1 1/8 10 1/8 Q4TS-100 2/0 Solid- 1000 kcmil 2 1/4 4 1 1/8 11 7/8 TYPE Q2TS, Q3TS, Q4TS Cast Copper multiple tee connector for securing a number of cables to a single transformer terminal.
161 Bronze Grounding Connectors and Everdur Hardware © 2011, AFL, all rights reserved. PP-3-00476, Revision 1, 1.30.19 Specifications are subject to change without notice. Bronze Grounding Connectors and Everdur Hardware www.AFLglobal.com or 800-890-8878 This connector is designed for transformer grounding pads. Connector stud possesses a slight taper to insure sound electrical contact without need for locking devices. Designed specifically for use on all standard EE-1-NEMA distribution transformers. Material Copper Alloy Hardware Everdur nuts and lockwashers TYPE TGC Grounding Connector For Cable To Transformer Ground Pad Ordering Information CATALOG NO. FIG. NO. ACSR RANGE DIMENSIONS IN INCHES BOLT SIZE MIN MAX A B C D E F H TGC8-50 1 #10 SOL #1 STR 1 3/8 11/32 9/16 7/8 7/8 1/2"-13 1 5/8 3/8 TGC13-50P 2 #8 SOL 2/0 STR 2 11/16 3/8 3/4 1 13/64 1 1/8 1/2"-13 1 4/5 3/8 TGC25-50 2 #6 STR 250 MCM 2 3/8 3/8 3/4 1 9/16 1 1/2 1/2"-13 2 11/32 1/2 TGC25-75 2 #6 STR 250 MCM 2 13/16 21/32 1 1 3/4 1 1/2 3/4"-10 2 11/32 1/2 C D H A E B ∅ F D H E C A B ∅ F FIG. 1 FIG. 2
Características:
- Aleación de bronce
Aplicaciones:
- Calificada para 230 kV
- Subestación
Conectores de transformador atornillados de bronce
Acopladores de compresión de aluminio de 230 kV,Conectores en T de compresión de aluminio de 230 kV,Conectores de terminales de compresión de aluminio de 230 kV,Acopladores de tubería de aluminio soldado de 230 kV,Codos de aluminio soldados para tubos de bus de 230 kV,Soportes de tubería de aluminio soldado de 230 kV,Conectores en T y en V para tubos de aluminio soldados de 230 kV,Conectores de terminales de tubería de aluminio soldado de 230 kV,Acopladores de aluminio soldado para cables de 230 kV,Tubería de aluminio soldada de 230 kV a T de cable,Terminal de cable soldado de aluminio de 230 kV,Tapones de aluminio soldados de 230 kV,Varilla de tierra soldada de aluminio de 230 kV,Derivaciones de tubos soldados de aluminio de 230 kV
365
Close
Conectores de bronce para transformadores de 230 kV
Características:
- Aleación de bronce
Aplicaciones:
- Calificada para 230 kV
- Subestación
PRODUCT DESCRIPTION
Conectores de transformador atornillados de bronce
